Vacuum Bagging Supplies for the Amateur and Professional
Vacuum Bagging Pressure Kit
Simple, Effective Kit Runs Off-Shop Compressors

FIG 5541

This complete starter kit will handle repairs and small laminating projects up to 13 square feet
and can be powered by conventional shop air compressors that deliver as little as 60 psi at two
static cubic feet per minute. A key element of the kit is the Venturi vacuum generator developing
more than 10 psi and removing more than one static cubic foot of air per minute. Vacuum pres-
sure makes it possible for an entire schedule of laminate materials to be laid up at one time and
will hold all in place at any angle or attitude. This method provides firm, even clamping pres-
sure over the entire surface area. It also allows rapid cure with a small application of heat.
Vacuumed laminates are uniform, strong and have greater fabric density than friction or gravity-
held laminates. This inexpensive, easy to use kit converts standard shop air to vacuum, making
the vacuum bagging advantages readily available at any repair yard or shop.
The Vacuum Bagging Kit Contains:
Venturi Vacuum Generator with Release Fabric (15 sq. ft.)
Bronze Muffler Breather Fabric (15 sq. ft.)
Vacuum Cups (2) Vacuum Bag Film (15 sq. ft.)
1/4" I.D. Vacuum Tubing (10 ft.) Vacuum Bag Sealant Tape (25 ft.)
Vacuum Gauge 0-30 Hg. Complete Kit Instructions (32-
Junction "T" Barbs (2) page Manual "Advanced Vacuum
Bagging Techniques")

No. Each Description Case
885 $254.56 Complete Vacuum Bagging Kit 1
885-5 43.45 Spare Vacuum Gauge 0-30 Hg 4
885-34 39.05 Vacuum Cups (3) and 10 ft. of 1/4" I.D. Vacuum Tubing 12
Vacuum Bag Film Vacuum Bag Sealant Tape

WEST SYSTEM EPOXY Clear, heat-stabilized blown film produced from modified nylon Mastic tape sealant for air-tight vacuum seals. Easy to work

FIG 5530
FIG 5531
resin. Can be used at temperatures up to 400°F (204°C) for typi-
cal composite cure cycle times. 60" wide.
No.
Roll
Size
around difficult angles, patching small leaks in the vacuum bag.
$138.85
882-20
Roll
SOLD IN FULL ROLLS ONLY
$15.90
1/2" x 1/8" x 25 ft.
883
879 Release Fabric 60" x 20 yds. No. 881 Breather Fabric Size
"Baby Blanket"

FIG 5540
FIG 5539
881 Breather Fabric is an inexpensive, lightweight, polyester
879 Release Fabric is an economical, tough nylon fabric that blanket that provides excellent air passage within the vacuum
separates the absorber, breather and vacuum bag from the envelope while it absorbs excess epoxy. Used together with
laminate (it works like peel ply). It peels away easily, leaving a 879 Release Fabric (See Fig. 5539), these fabrics improve vac-
smooth textured surface that is ready for bonding or finishing. uum clamping results while decreasing the cost of vacuum
Use with 881 Breather Fabric — See Fig. 5540. laminate operations.
No. Roll Size Case No. Roll Size Case
879-10 $165.90 60" x 10 yards 1 881-10 $89.00 45" x 10 yards 1
