9. Steering www.lewmar.com

The Lewmar Steering Range Steering Overview

Constellation™ System – Wire steering
Constellation™ is the main wire steering system available for
Page 347 Steering Systems
yachts from around 7m/25ft – 18m/60ft. They can be in either
• Comprehensive range of steering systems • Cobra – Rack and Pinion single or tandem systems - ideal for aft cockpit installations - and
• Constellation – Open wire and wire-in-conduit • Mamba – Rotating Torque Tube and Bevelhead are the most reliable systems on the market. The conduit system
steering. overcomes the diffi culties that are experienced when using open
wire in centre cockpit installations.

Page 365 Rudder bearing

• Range of rudder bearings complement Lewmar • Suitable for tiller-steered and
Steering Systems wheel-steered yachts Cobra™ System – Rack and Pinion
• Full range of accessories The Cobra™ system is an industry leader in its fi eld and designed
for aft-cockpit yachts. The system uses rack and pinion to ensure
the necessary mechanical advantage required for sensitive steering.
Page 366 Wheels Lewmar also offers a bespoke Cobra™ system for use on non-aft
cockpit yachts.
• Choice of wheels to suit any application • Compatible with all Lewmar Steering Systems
• 25mm/1” tapered keyed shaft ensures • Full range of accessories available
positive fit

Page 373 Pedestals
Mamba™ System – Rotating Torque Tube and Bevelhead
• Range of standard and custom pedestals • Custom pedestals available for
bespoke specification
• Modern composite construction guards Mamba™ is a suitable system for a diverse range of sail boats, from
against corrosion • Range of accessories available, bluewater cruisers to round-the-world racers. It offers unique
including guardrails
features - such as variable mechanical advantage steering - while
retaining versatility in the type of installation, such as tandem
systems. The Mamba™ system ensures positive steering feedback
Page 377 Instrument Pods and strength; inherent benefi ts in gearbox and bevel head steering
systems.
• Choice of instrument pods to suit any • Pods available as retrofit or complete assembly
electronic configuration option

Track and Car System

Page 380 Cockpit Accessories Lewmar's revolutionary track and car steering system is an
innovative blend of product experience. Constellation™ wire
• Range of cockpit tables in different finishes • Tables and pods designed to complement extends from the pedestal and connects to our proven,
Lewmar Pedestal Range
marine-grade, ball bearing traveller car and track. Then, using the
components of the Mamba™ solid system, it connects the track
and car to the rudder blades. The entire system is lightweight
with multiple mounting possibilities and responsive feedback when

Page 381 Autopilot Drives sailing.

• Simple installation • All units feature electromechanical clutch
• Compatible with main electronic suppliers • Low current draw
