Delta T Systems Modular Exhaust

By DINAK

Two Year Warranty

Modular Component Design
• Preset piping lengths, adjustable piping lengths, multiple elbow configurations and terminus
arrangements as well as a full selection of mounting brackets

Pieces Can Be Easily Removed and Reinstalled Without Damaging the Components

Units Designed to Accommodate Thermal Growth
• Inner wall and outer sheath for each section has integrated bellows geometry where required

No Welding Necessary
• No custom fabrications required and all components are predefined and ready to install

Extremely Simple and Quick Installation
• Does not require any formal training or specialized tradesman for installation

Proven Track Record
• Product has been used successfully with many European shipbuilders for almost two decades

Installation Drawings Provided
• A full system drawing package is provided with each system with clear definitions of
component locations

OPTIONS

DNV Type Approved Dry Mufflers - Coated Carbon Steel or Stainless Steel (Muffler insulation
quoted upon request)
DNV Type Approved Muffler Performances Offered
• 18-25dBa, 30-35dBa, 35-40dBa

Expansion Joints and Joint Insulation

Primary expansion joint from engine should be procured by customer from engine manufactur-
er. DTSI can quote upon request.

Custom Components Can Be Fabricated Upon Request

Engineering Services Available
• For retrofits and difficult new builds, DTSI can dispatch engineer on site to design system that
will be guaranteed to fit within the vessel (this service is quoted above the system pricing,
travel, field rate, expenses)
