REFERENCE

Modular Switching System

Imtra is the supplier of choice for the marine industry’s most popular decorative switching system. Designed and manufactured in Italy,
Vimar ® switching is available in three distinct collections: Idea, Eikon and Arké. Each series boasts over 200 functions (switches, dimmers,
outlets, sockets, etc.) with dozens of cover plate choices in a variety of configurations, colors and materials. For the ultimate in on-board
lighting command and control, Vimar’s By-me Marine ® automated control system is user-friendly, easy to program, and simple to install
and maintain. Download a Vimar catalog
at www.imtra.com.

IP Ratings Warranty & Reliability
The IP rating (Ingress Protection Rating) designates the amount of dust or fluid At its discretion, Imtra will either replace or repair any product in this catalog within
an electronic/electrical enclosure allows to pass through into the product. its specified warranty period if found to be defective through faulty material or
The rating applies to any enclosure that provides protection of equipment from workmanship provided that no attempt has been made by the customer to tamper
certain external influences and in any direction, along with protection against with, rectify, dismantle, or alter the product in any way. The warranty periods for
direct contact. most products are specified in the preceding catalog pages and commence upon
IP20 (2) Protected against penetration of solids larger than 12mm and delivery of the goods. Warranty periods listed in this catalog refer to electronic
(0) not protected against liquids functionality only. If not defined in the catalog, please locate detailed warranty
IP40 (4) Protected against penetration of solids larger than 1mm and information on any specific product by downloading that product’s installation
(0) not protected against liquids manual directly off our website. Imtra specifically disclaims any implied warranties,
merchantability or fitness for a specific purpose and will not be liable for any direct,
IP50 (5) Protected against dust and (0) not protected against liquids
indirect, incidental or consequential damages. Imtra’s total liability is limited to
IP55 (5) Resistant to dust penetration and (5) protected against jets of repair or replacement of the product. The warranty set forth above is inclusive
water from every direction
and no other warranty, whether written or oral, is expressed or implied. If it should
IP65 (6) Completely protected against dust and (5) protected against become necessary to return a fixture for service during or beyond the warranty
jets of water from every direction
period, please refer to Imtra’s standard Return Policy as detailed on Imtra’s website
IP67 (6) Completely protected against dust and (7) protected against (www.imtra.com) or call Imtra customer service at (508) 995-7000. No returns will
immersion (30 minutes, 1m+ depth) be accepted without a Return Authorization (RA) number.

Photo Credits
Classification Symbols Imtra would like to thank the following boat builders, photographers and
Imtra lighting products are designed to meet international standards companies for allowing us to use their images in this catalog:
and classifications. Symbols identifying these classifications are: Ed Dickson Photography, Hy-Line Cruises, Nordhavn Yachts, Marine Group,
Outer Reef Yachts, Sabre Yachts, Tiara Yachts, Duffy Boats and Zurn Yacht Design.
European Conformity Meets or Exceeds FCC
Mark of Approval Standards
Compliant to Restrictions ABS Design Assessed
of Hazardous Substances
Directive
Suitable to Inflammable C-Tick Safety Mark
Surfaces
Class 3 Russian Maritime Register
of Shipping Certified
Class 1 Tested & Approved by
Det Norske Veritas
Tested and Approved by Certified to Applicable Public
ETL to meet U.L. Standards Health & Safety Standards
30 Samuel Barnet Boulevard, New Bedford, MA 02745
Tested and Approved by Tested & Approved by 508.995.7000 www.imtra.com
U.L. to meet U.L. Standards TUV Labs
Trade Agreement Act USDA Compliant
Compliant
ANSI-ASQ National Designed & Assembled
Accreditation Board in the U.S.A.
© 2017 Imtra Corporation. Printed in U.S.A. IMTRA is a registered trademark of Imtra Corporation
All specifications are subject to change without notice.
