Deck Plate and Removable Eye Pad Eyes

78-82 78-81-02

78-81
FIG 8184b

Stainless steel eye screws into 3" stainless steel deck
plate. Welded eye (5/8" diam. and 3/4"-10 thread) allows easy
attachment of snap-shackles, snatch blocks, etc. When not
needed, remove eye and replace with hi-impact nylon screw
No. 78-81-02. Use 4 No. 1/4" F.H. fasteners.
ALL ITEMS SOLD SEPARATELY
No. Each Description
78-81 $141.50 Deck Plate Only
78-82 68.55 Screw Eye
78-81-02 25.65 Hi-Impact Nylon Screw
Pad Eyes

FIG 8180b PAD EYES
97-42

78-01 PAD EYE: Base 1" x 3" x 1/8" thick. 1/4" diameter eye,
7/8" I.D. S.W.L.: 2,500 lbs. Use No. 1/4" R.H. fasteners. 97-51
BACKING PLATE FOR PAD EYE.
No. Each Description
78-01 $36.75 Pad Eye
97-51 18.25 Backing Plate
97-52
Pad Eye

FIG 8181b

97-42 PAD EYE: Cast stainless steel pad eye. 3" square base,
1/4" thick. 5/16" thick eye has 3/4" inside diameter. S.W.L.:
5,000 lbs. 97-52 backing plate for 97-42 pad eye.
No. Each Description
97-42 $78.30 Pad Eye
97-52 28.75 Backing Plate

Pad Eyes

78-03 78-05

FIG 8204
FIG 8182b
78-05 PAD EYE: Base 5/8" x 2-1/4". 1/2" Inside eye diameter.
Use No. 10 R.H. fasteners. 78-03 PAD EYE: base 5/8" x 2". 1/2"
Inside eye diameter. Use No. 10 R.H. fasteners. PAD EYE: Investment cast stainless steel on 2-1/2" delrin base.
No. Each S.W.L.: 5,000 lbs. Use No. 1/4" F.H. fasteners.
78-03 $26.45 No. Each
78-05 32.65 78-07 $66.15
S.W.L. — Safe Working Load
