204 Clamcleats, Fairleads and Winch Handles

Clamcleat Rope Cleats

CL201 CL203

CL204 CL209
FIG 1757b

These clamcleat rope holding devices are used mostly for racing and cruising on everything from dinghies to ocean racers. They are
available in a variety of configurations to fit many applications on mainsheets, travelers, jib sheets, genoa sheets, halyards, vangs,
spinnaker sheets and control lines of all types. Made of strong, durable black plastic.
Line Tensile A B C Screw
No. Each Description Diameter Strength Width Length Height Size
CL201 $10.65 Vertical 1/4" - 1/2" 1000 lbs. 1-1/8" 3-3/4" 1-1/2" No. 14
CL203 5.40 Junior 1/8" - 1/4" 200 lbs. 11/16" 3-1/4" 15/16" No. 8
CL204 4.30 Mini 1/8" - 1/4" 200 lbs. 5/8" 2-1/16" 3/4" No. 8
CLAMCLEATS, FAIRLEADS AND WINCH HANDLES
CL209 5.40 Midi 3/16" - 5/16" 500 lbs. 3/4" 2-7/8" 1-1/32" No. 10
Thru-Deck Fairlead

FIG 8177b

PLASTIC THRU-DECK FAIRLEAD: thermoplastic construction resists frictional heat. For up to 1/4" rope.
No. Each
76-06 $22.10
Fast Turn Ball Bearing Winch Handles Lewmar Winch GearGrease

1110

1111

FIG 1370

FIG 13704 A new generation, top quality, complex calcium sulphonate
based grease, with exceptional performance properties. Excel-
lent for assembly application and all-round lubrication of
These handles use twin ball-races to provide a "feel" and an marine equipment. Simply apply a thin film to all mating sur-
effortlessness no ordinary handle can match. They fit any inter- faces when assembling and lubricating equipment following
national-standard winch socket. Available with a handy two-way manufacturer's recommendations, to aid the prevention of
lock-in feature, which keeps the handle firmly on the winch. galling and dissimilar metal corrosion. Recommended for the
Releasing the handle is quick and simple, using either hand; you lubrication of winches, windlasses, steering gears, bearings,
just push the spring-loaded release to the left or right. trailer wheel bearings, hydraulic equipment, outboard engines
No. Each Size Type Finish and many other marine applications.
1110 $106.10 10" Standard Aluminum No. Each Description
1111 123.65 10" Lock-In Aluminum 7010 $22.75 Multi-Purpose Winch Grease – 3.5 oz. Tube
