438 Strainers

Single Sea Strainers for Engines
SA-S Series
FIG 9943

All bronze with a 304 stainless steel filter basket and monel inside tie rod. Features an easy service spin-off wing
nut and drain plug.
No. Each Pipe Size Diameter x Height Weight
SA750S $401.75 3/4" 4" x 9-1/16" 4.40 lbs.
SA1000S 526.35 1" 5" x 10-1/2" 6.92 lbs.
SA1500S 824.80 1-1/2" 6-1/4" x 13-3/4" 12.25 lbs.
SA2000S 1068.95 2" 6-1/4" x 16-1/2" 16.20 lbs.
SA2500S 1185.60 2-1/2" 6-1/4" x 18-3/4" 18.40 lbs.
SA3000S 1332.90 3" 6-1/4" x 21-1/2" 21.25 lbs.

Swivel-Mount Sea Strainer

FIG 2133

The Universal Mount Strainer is made of cast bronze with a
pull-out strainer screen. The inspection lens is heavy-walled
and fastened to the housing with a bronze retainer ring plate.
A 360° rotation of top housing optimizes plumbing fittings.
Dimensions
No. Each Inlet/Outlet A B C
3/4 $195.80 3/4" IPS 7-1/2" 5-7/8" 5-9/16"
1-1/2 314.25 1-1/2" IPS 10-9/16" 6-3/4" 6-3/8"
2 466.15 2" IPS 14" 10-13/16" 9-7/8"
SPARE PARTS FOR STRAINERS
SB75 49.80 Replacement Cylinder for 3/4" Strainer
SB150 74.70 Replacement Cylinder for 1-1/2" Strainer
SB2 175.10 Replacement Cylinder for 2" Strainer
SS75 42.70 Spare Screen for 3/4" Strainer – 4.475" H x 1-1/2" Diameter
SS15 56.95 Spare Screen for 1-1/2" Strainer – 7.045" H x 2.25" Diameter
SS20 67.80 Spare Screen for 2" Strainer – 9.690" H x 3" Diameter
SC75 74.00 Spare Cap for 3/4" Strainer
SC15 101.30 Spare Cap for 1-1/2" Strainer
SC20 146.75 Spare Cap for 2" Strainer
SK75* 32.00 Repair Kit for 3/4" Strainer
SK15* 30.50 Repair Kit for 1-1/2" Strainer
SK20* 34.25 Repair Kit for 2" Strainer
*Repair kits contain 2 O-Rings, 8 allen head screws and 1 drain plug.

Sea Water Strainers
STRAINERS Mounting Bracket This illustration shows how

flow is channeled uniformly
through the screen in
Sold Separately
Sherwood line strainers.
FIG 1921
Made of non-corrosive plastic. Ports feature stainless steel ferrule reinforcements. All screens are mesh stainless
steel. Mounting bracket sold separately.
No. Each IPS Port Size Type Screen Mesh
18004 $51.75 1/2" Female 40
18001 42.15 3/4" Female 20
18005 70.00 1" Female 20
18016 77.95 1-1/4" Female 20
18029 88.00 1-1/2" Female 20
SHERWOOD STRAINER PARTS
No. Each Description Diameter x Length Strainer IPS
11805 $9.20 O-Rings — 1/2" & 3/4"
11803 9.35 O-Rings — 1", 1-1/4", 1-1/2"
11807 25.75 20 Mesh Screen 2-1/4" x 4-1/4" 1"
11810 20.40 20 Mesh Screen 1-1/2" x 3-5/8" 1/2 & 3/4"
11811 22.35 40 Mesh Screen 1-1/2" x 3-5/8" 1/2 & 3/4"
14214 28.45 20 Mesh Screen 2-1/4" x 4-1/2" 1-1/4"
16126 27.90 20 Mesh Screen 2-1/4" x 5-1/2" 1-1/2"
14239 38.75 Mounting Bracket — 1"
14240 24.20 Mounting Bracket — 3/4"
14238 34.00 Mounting Bracket — 1-1/4"
