PVC Threaded Fittings 465

Threaded PVC Pipe Fittings Schedule 80
NOTE: "S" Designates Slip "T" Designates Thread
Nipples Plug Caps

FIG 8471

Threaded.
No./I.P.S. Each No./I.P.S. Each FIG 8468
1/2"xCL $1.70 3/4"x6" $4.30 FIG 8470
3/4"xCL 2.60 1"x3" 2.95 Threaded.
1"xCL 2.95 1"x6" 5.95 No./I.P.S. Each
1-1/4"xCL 4.30 1-1/4"x3" 5.05 1/2" $6.90 Threaded.
1-1/2"xCL 4.75 1-1/4"x6" 7.40 3/4" 7.20 No./I.P.S. Each No./I.P.S. Each
1/2"x3" 2.55 1-1/2"x3" 6.60 1" 8.80 1/2" $8.90 1-1/4" $15.00
1/2"x6" 3.45 1-1/2"x6" 8.90 1-1/4" 12.85 3/4" 10.00 1-1/2" 17.15
3/4"x3" 2.60 1-1/2" 15.70 1" 12.65
Reducer Bushing Female Adapter Coupling
Male to Female Slip x Female Thread

FIG 8462

FIG 8467
Long thread to thread. FIG 8463
No./I.P.S. Each No./I.P.S. Each
3/4"x1/2" $9.05 1-1/4"x1" $15.00 Thread to thread.
1"x1/2" 14.15 1-1/2"x1/2" 17.80 No./I.P.S. Each No./I.P.S. Each No./I.P.S. Each No./I.P.S. Each
1"x3/4" 14.15 1-1/2"x3/4" 17.80 1/2" $6.80 1-1/4" $24.30 1/2" $8.15 1-1/4" $15.50
1-1/4"x1/2" 15.00 1-1/2"x1" 17.80 3/4" 10.15 1-1/2" 29.75 3/4" 11.70 1-1/2" 34.50
1-1/4"x3/4" 15.00 1-1/2"x1-1/4"17.80 1" 13.45 1" 12.55

90° Ell 45° Ell

FIG 8464 FIG 8465

Thread to thread. Thread to thread.
No./I.P.S. Each No./I.P.S. Each No./I.P.S. Each No./I.P.S. Each
1/2" $9.35 1-1/4" $15.75 1/2" $15.00 1-1/4" $31.80 PVC THREADED FITTINGS
3/4" 11.65 1-1/2" 22.40 3/4" 16.15 1-1/2" 38.75
1" 14.65 1" 20.25

Tee Check Valve

FIG 8466
FIG 8786
All thread.
No./I.P.S. Each No./I.P.S. Each
1/2" $13.20 1-1/4" $34.30 No. Each M.P.T.
3/4" 14.65 1-1/2" 41.55 Q2500 $7.40 1/2" x 1/2"
1" 32.35 Standard Package – 100
Recommended Thread Sealant – Teflon Tape — See Fig. 3436 or Fig. 6078
