P. 488
Hynautic Numerical 487
FIG 1HYN
No. Each Description No. Each Description
K33 $1014.00 Hydraulic Cyl. – Hatteras, 22.8 CID MCT01 $79.65 5/16" OD x 50 ft. Nylon Tube, 500 psi
KH01 50.20 Ball Joint Bolt Kit K1B, K2B, K3B, K5 MCT02 151.65 5/16" OD x 100 ft. Nylon Tube, 500 psi
KS01 47.65 Cyl. Repair Kit for K11 to K17 MCV04 315.30 Charging Valve – Engine Control
KS02 47.65 Cyl. Repair Kit for K18 to K20 MCVF04 146.65 Charging Valve Fitting – Dual Engine
KS04 47.65 Cyl. Repair Kit Pre-8/83 for K22 to K29 MCVF05 94.25 Charging Valve Fitting – Single Engine
KS05 47.65 Cyl. Repair Kit for K31 to K33 MCVF08 190.50 Charging Valve Fitting – Rebuilt
KS06 47.56 Repair Kit for K22 to K29 after 8/83 MSH5 3.30 5/16" ID Reinforced Hose Per Foot 950 psi
KS07 47.65 Repair Kit for K10 MSH5-50 187.25 5/16" ID Reinforced Hose 50 ft., 950 psi
MANY PARTS
KS11 47.65 Seal Kit for K1B, C & PSK10B MSH5-100 374.50 5/16" ID Reinforced Hose 100 ft., 950 psi
KS12 47.65 Seal Kit for K2B & C MSH6 5.70 3/8" ID Reinforced Hose Per Foot 950 psi
KS13 47.65 Seal Kit for K3B & C, K4B & C MSH6-50 322.20 3/8" ID Reinforced Hose 50 ft., 950 psi
AVAILABLE
KS15 47.65 Seal Kit for K5 MSH6-100 644.45 3/8" ID Reinforced Hose 100 ft., 950 psi
WHILE SUPPLIES
KS17 49.20 Repair Kit for K3 & K4 MSH6-600 3192.40 3/8" ID x 600 ft. Hydrulic Tubing
KS18 49.20 Seal Kit for K8 & K9 MSRF01 105.60 Fitt. Pkg. for 3/8" Copper Tube or MSH5, 6
KS19 49.20 Repair Kit for K6 for R06, 07 Reservalve
MCO2G 70.35 Hydraulic Steering Oil – Gallon MSV19 247.45 500 PSI Relief Valve
MCO3G — See Fig. 6564 No. HA5455 MSV21 273.80 950 PSI Relief Valve
LAST
MC04S1 4406.30 Eng. Control Sys., 1 Eng. 1 Station MSVF13 66.35 Relief Valve Fitting Package for MSV21 for K2, 3, 31
MC04S1D 4458.35 Eng. Control Sys., 1 Eng. 1 Station, Dual Head & H40, 1/2" Copper or Hose & 3/8" Return
MC04S2 5999.55 Eng. Control Sys., 1 Eng. 2 Station 3/8" Copper & 1/4" Return
MC04S2D 6103.70 Eng. Control Sys., 1 Eng. 2 Station, Dual Head PSV10 444.90 Seq. Relief Valve – Power Steering Systems
MC04S3 7592.85 Eng. Control Sys., 1 Eng. 3 Station R04 725.15 Reservoir with 0-100 psi Gauge Controls
MC04S3D 7749.00 Eng. Control Sys., 1 Eng. 3 Station, Dual Head R13 1093.75 Reservoir & Valve for Controls – 150 psi HYNAUTIC NUMERICAL
MC04T1 7728.65 Eng. Control Sys., 2 Eng. 1 Station RS01 52.50 Reservoir Seal Kit
MC04T1D 7832.74 Eng. Control Sys., 2 Eng. 1 Station, Dual Head SS04 704.25 Transmission Slave for Hydraulic Controls
MC04T2 10915.20 Eng. Control Sys., 2 Eng. 2 Station SSF04 136.25 Slave Fitting Package for Hydraulic Controls
MC04T2D 11123.40 Eng. Control Sys., 2 Eng. 2 Station, Dual Head ST04 635.50 Throttle Slave for Hydraulic Controls
MC04T3 14101.75 Eng. Control Sys., 2 Eng. 3 Station ST06 759.05 Throttle Slave Unit ( ST04 & STV10)
MC04T3D 14414.10 Eng. Control Sys., 2 Eng. 3 Station, Dual Head STF10 226.80 Slave Fitting Package for Hydraulic Controls
MCEF04 100.40 Extra Fittings – Engine Control STF12 162.90 Throttle Slave Fittings
MCRF04 49.85 Reservoir Fitting Package STV10 168.15 Check Valve for Hydraulic Controls
