Helm Parts and Accessories 491

Hynautic Seal Kits and Parts

FIG 1HYN

No. Each Description
HELM PARTS
900300 $162.99 Front Cover and Seal for H20 & H40 Series
HF07 73.05 Trim Package contains; 1-310034 Gasket, 4-340051 Nuts (3/8"-16), 4-390038 Gaskets
and 1-520061 – For 20, 30 & 40 Series Helms
HF35 31.75 Helm Purge Fill Kit for H60 Series Helms
HELM SEAL KITS
HS01 43.80 External Helm Seal Kit for Series 20 Helms (Old Style prior to 1978)
HS02 43.80 Internal Helm Seal Kit for Series 20 Helms (Current Style 1979 and After)
HS03 43.80 External Helm Seal Kit for 40 Series Helms (Old Style prior to 1978)
HS04 43.80 Internal Helm Seal Kit for Series 40 Helms (Current Style 1978 and After)
HS05 43.80 Helm Seal Kit for H50 Series Compact Helms
HS06 43.80 H60 Series Helm Seal Kit
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

SeaStar Helm Accessories
FIG 6564

SeaStar Helm Accessories Backplate Kit No. HA5418
for HH5271 and HH5272 Helms

HA5431
HP6126

a) Used to retrofit a new SeaStar standard helm in the old
HA5430 HA5432
4.5" diameter hole;
b) or reduce the helm protrusion from the dash by the thick-
ness of the dash;
c) or retrofit new SeaStar standard helm into hole cutouts
for mechanical and hydraulic steering as per chart.
No. Each Description
HA5418 $46.90 BackPlate Kit Converts Round Style HH5271 Steering Helm Model System Backplate
Kit Req.
Type
Manufacturer
Helm to Old Style HH5201 Square Face Helm
HA5419 91.90 20° Mount for Current Round Helms SeaStar Safe-T Mechanical Yes
HA5430 32.80 SeaStar Hydraulic Oil – 32 oz. Big-T Mechanical Yes
HA5431 9.95 Vented Plug for Single or Upper Station Helm Rack & Pinion Mechanical No
HA5432 15.10 Non-Vented Plug for Lower Station Helm Syten Hydraulic Yes
HA5438 23.20 Helm Filling Kit w/ 10 inches of 1/2" Tubing Morse Rotary Mechanical No
HA5440 104.85 SeaStar Hydraulic Oil – 1-Gallon Rack & Pinion Mechanical No
HA6523 333.05 Replacement Tilt Assembly – Classic Style
HF5501 165.55 Fitting Kit Additional Station Auto Pilot O/B Old Style New Style
Application with 25 ft. Return Line Square Round
HP6032 12.30 Service Kit for all SeaStar Helms: Locknuts,
Washers, Helm Nut, O-Ring, Woodruff Key HELM PARTS AND ACCESSORIES
HP6126 43.95 5-pk. Vented Plug for Single or Upper Station Helm
747521 3.25 Nylock Lock Nut for all SeaStar Helms
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
Helm Seals and Seal Kits

No. Each Description
Old Hynautic Helm Conversion Chart
225226 $4.30 Quad Ring Shaft Seal for SeaStar Helms HH5271, 72, HH5770, Hynautic Helm No. SeaStar Part No.
HH5741, 42 & HH5774 H316 HH5271-3
HS5147 16.70 BayStar Standard Front Mount and Sport Tilt Helms H320 HH5273-3
HH4015 & HH4016 H324 HH5272-3
HS5151 51.80 Seal Kit for Old Style Square Mount Block SeaStar Helms H816 HH5271-3
(From 1978-1990 to Current) H820 HH5273-3
HS5161 55.25 Helm Seal for HH5250 & HH5275 Capilano Helm H824 HH5272-3
