NO-SMELL FILTERS

No-smell filters for diesel tanks type NSFD/S
Remedy for escaping diesel fuel odours
With these filters diesel fuel smells can no longer escape through the
breather line which is required for all fuel tanks on boats.
The no-smell filters are easy to install and contain activated carbon
material to absorb odours. To avoid diesel fuel and froth entering the filter
housing and its element, it is imperative to install in combination with a
Splash-Stop (page 128). A VETUS no-smell filter should not be used for
petrol tanks.

Specifications
• Model NSFD: l 5 /16” x w 5 /16 ” x h 6 /8 ” (148 x 150 x 162 mm)
15
13
3
• Suitable for Ø /8”, /4” or 1’’ (16, 19 or 25 mm) connectors
5
3
• Model NSFDS: l 4 /32” x w 4 /16 ” x h 4 /16 ” (107 x 111 x 111 mm)
7
9
9
• Only suitable for Ø /8” (16 mm) breather hose
5
NSF..D NSF16DS
Please note
The filter element is replaceable. Replacement can be done with traditional
carbon filters or with the improved solution: the dual function filter canister
type NSFCAN. It should be renewed once a year.
Type Description L x W x H inches (mm) Hose Ø inches (mm)
NSF16D Large no-smell filter 5 /16 x 5 /16 x 6 /8 (148 x 150 x 162) 5 /8 (16)
3
15
13
3
15
13
NSF19D Large no-smell filter 5 /16 x 5 /16 x 6 /8 (148 x 150 x 162) 3 /4 (19)
NSF25D Large no-smell filter 5 /16 x 5 /16 x 6 /8 (148 x 150 x 162) 1 (25)
3
15
13
NSF16DS Small no-smell filter 7 /32 x /16 x /16 (107 x 111 x 111) 5 /8 (16)
49
49
NSF16FES Spare filter element for small no-smell filters
NSF16FE Spare filter element for large no-smell filters
No-smell filters element type NSFCAN
Revolutionary dual function
Type NSFCAN is a pre-filled canister with a measured quantity of
activated carbon and special gel granules. The combination of gel
granules and carbon provides a perfect dual function. Traditional carbon
filters often lose efficiency due to humidity and condensation. The gel
granules in this filter absorb the moistures which cause the efficiency loss
and also ensure significantly less air borne moisture allowed into the fuel
tank.
Specifications
• Suitable for new and existing VETUS no-smell filters type NSFD
• Transparent cover so you can easily see when the special gel is
saturated and replacement of the canister is necessary
• The filters reduce the risk of mould and ‘diesel bug’ in the tank NSFCAN NSFCANS
(moisture in diesel fuel can be a perfect breeding ground for mould
and bacteria)
• The smaller version type NSFCANS can be used with no-smell filter
NSF16DS

Type Description
Odour absorbing Special moisture
NSFCAN Dual function no-smell filter canister for type NSF filters
activated carbon absorbing granules
NSFCANS Dual function no-smell filter canister for type NSF_S filters

Creators of Boat Systems 133
