STEERING WHEELS

Type PRO
The perfect match for traditional and modern boats
Type PRO has 2 models. Type ‘T’ with a satin-gloss varnished teak rim and type ‘P’ with a semi-hard polyurethane rim which
will keep your hands warm. Both models have substantial spokes and a hub cover made of high-gloss polished stainless steel
(AISI 316). The hub itself is made of synthetic material and bored for a ؾ” shaft with 1:12 taper which will fit most steering
systems. These steering wheels are according to the CE and ABYC directives.
Specifications
• Available with overall diameters of 16”, 20” or 24” (600 mm), (400, 500 or 600 mm)
1
• Outer rim Ø 1 / 4” (32 mm)
Note: An alternative hub to suit older VETUS steering pumps with a Ø1” hole shaft and 3½:12 taper is also available
(product code: SETPS1).

PRO..P PRO..T

Ø inches Ø Outer rim
Type Description
(mm) inches (mm)
1
PRO40P Polyurethane rim steering wheel 16 (400) 1 /4 (32)
PRO50P Polyurethane rim steering wheel 20 (500) 1 /4 (32)
1
PRO60P Polyurethane rim steering wheel 24 (600) 1 /4 (32)
1
Ø 600 Ø 600 Ø 600 Ø 500 Ø 500 Ø 500 Ø 400 Ø 400 Ø 400
1
PRO40T Teak steering wheel 16 (400) 1 /4 (32)
PRO50T Teak steering wheel 20 (500) 1 /4 (32)
1
PRO60T Teak steering wheel 24 (600) 1 /4 (32) 44 44 44
1
48 48 48
53 53 53

PASBUS A
All VETUS wheels and steering pumps have a Ø ¾” bore, with a 1:12 taper. The PASBUS is a tapered
bushing that can be applied to the ¾” shaft of a steering pump so that it can receive a wheel with
a 1” bore. This allows wheels made by others to be installed on our pumps.

PASBUSA
