CABIN
CABIN D ANISH LIGHT S
Key Features & Benefits
• The original Cabin “Frigast” yacht lights
• Stainless steel construction
• May be fitted with high output G4 bi-pin LED bulb
LED Colors
Single Color: Warm, Cool
2 YEAR
Specifications* Cabin Ocean Ocean Chart Cabin
Beam angle (FWHM) 120 O
Power consumption 2.2W
Luminous flux (lm) 120
Lifetime hours (70% light output) 25,000
Halogen equivalency 10W
Input voltage 10-30VDC Ocean
Ingress protection (IP) IP20
* Specifications are based on use with X-Beam Warm White LED bulb
C
Finishes C
Polished stainless steel • •
• B
PVD Gold
• B
Chromed brass
A
A
Dimensions- Cabin
A Shade/Bell Diameter 3.63" 92mm
B Mounting Base Diameter 3.63" 92mm
C Extension From Wall 5.13" 130mm
Dimensions- Ocean Small Medium
Cabin Sailboat A Shade/Bell Diameter 2.88" 73mm 3.63" 92mm
Spreader Light B Mounting Base Diameter 3.63" 92mm 3.63" 92mm
Key Features & Benefits C Extension From Wall 4.38" 111mm 5.00" 127mm
• Models for deck & up light (mast) illumination Dimensions- Ocean Chart Small Medium
• Elliptical optics for efficient deck illumination
A Shade/Bell Diameter 3.00" 76mm 3.63" 92mm
• Designed to fit shape of modern spreaders B Mounting Base Diameter 3.63" 92mm 3.63" 92mm
• Long lasting titanium anodized finish C Extension From Wall 15.75" 400mm 15.75" 400mm
• Suitable for 12V & 24V systems
