Gauges 153

Heavy-Duty Deluxe Line Gauges (polished stainless steel bezels) are for 12-Volt DC negative ground systems. Dropping
resistors are available for other voltages. Electrical gauges and tachometers utilize rugged vector movements, with silicone
dampening to prevent pointer bounce. All movements are magnetically shielded to eliminate magnetic interference with
other gauges, electronic devices or the vessel's compass. Reverse polarity protection is provided.

Fuel Level Gauge

FIG 6053 GAUGES

Registers 240-33 Ohms (240 in empty position). Requires a fuel level sender. 2-1/8" diameter nylon case. Light kit is INCLUDED.
ORDER SENDER SEPARATELY
No. Each Bezel Range
80150P $50.40 Polished S/S E-1/4-1/2-3/4-F
For Sender No. 90424P — See Fig. 7711
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
Ammeter Voltmeter

FIG 6052
FIG 6054
Indicates generator or alternator charging rate and warns of
excessive drain by accessories. 2-1/8" diameter nylon case.
Light kit is INCLUDED. Monitors condition of battery, voltage regulator and generator
No. Each Bezel Range Type or alternator. 2-1/8" diameter nylon case. Light kit is INCLUDED.
80710P $54.95 Polished S/S 60-0-60 Internal No. Each Bezel Volts Range
Shunt 80134P $51.85 Polished S/S 10-16
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
For Light Kits — See Fig. 3225
