Page 254 - Lewis

Flush Hatch Lifting Handles 253

Slam Latch Square "D" Handle Latch

FIG 2155

Made of 316 stainless steel. Installs in 2" hole.
No. Each A B C E-Max E-Min FIG 2159
6096 $52.10 2-3/8" 2" 1-5/8" 3/4" 3/8"
Made of 316 Stainless Steel. The handle can be nested in the
Locking Flush Hatch Pulls latched or unlatched position. It also has a red dot to indicate
Chrome Brass unlatched position. Requires 2" hole.
No. Each Description
1264-2 $62.95 Non-Locking Latch

Flush Hatch Lifting Handle
Stainless Steel

1-99A 2-99A

FIG 777

This is a high-quality, heavy-duty latching mechanism. It is
made of chrome-plated brass and stainless steel. Has an O-ring FLUSH HATCH LIFTING HANDLES
seal on the shaft with a 5/16" Cam Bar (No. 0-99A) and easy grip
"T" handle. 2" maximum hatch thickness. Size: 3-13/16" L x 3" W. FIG 6040b
Takes No. 8 fasteners, NOT included.
Cam Bar
Fig. No. Each Adjustment Description Highly polished stainless steel.
777 — $184.20 1-1/4" - 2" Chrome Brass Hatch Pull No. Each Length Width Screw No.
777 1-99A 37.15 1-1/4" - 2" Spare Cam Bar – 1-1/2" S223C $12.10 3" 2-1/4" 8
777 2-99A 37.15 1-1/4" - 2" Spare Cam Bar – 3" Standard Package –5
Standard Package – 5
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov Flush Hatch Lifting Handles
Flush Turning Lock Lift Handle
Stainless Steel

No. 1 No. 2

FIG 776b

FIG 9704 Chrome-plated pressure cast silicon bronze with a stainless
steel pin. No large recess to catch chairs, heels, table legs, etc.
Plate dimensions for No. 1 is 3" L x 2-1/4" W — inside handle is
This is an all stainless steel handle with flush mounting. It lifts 1-7/8" L x 1" H; No. 2 is 3-3/4" L x 2-3/4" W — Inside Handle
and rotates, unlocking hatch or seat. O-ring seal in mechanism 2-3/16" L x 1-3/16" H. Uses No. 8 fasteners, NOT included.
assures leak-free operation. Adjustment is secured with stain- No. Each Description
less allen set screws in locking arm. 1 $73.40 Chrome Bronze
Base Overall Locking Screw 2 94.60 Chrome Bronze
No. Each Size Height Adjustment Size Standard Package – 5
221835-1 $85.90 3"W x 3-3/4"L 6" 1-1/4" x 3-3/4" 8 WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
