Heat Exchangers 415

In-Line Zinc Pencils Heat Exchanger End Cover Assemblies

End Rubber
Cover Gasket

FIG 6534 Bolt Fiber Washer
FIG 6533
These are used to help prevent galvanic action in the water
lines, to otherwise unprotected water coolers and heat 5372 does NOT have a fiber washer.
exchangers. Contains an internial strainer to protect oil cooler Maximum torque on bolt 2 ft. lbs.
and heat exchanger. SHOULD BE GROUNDED. No. Complete Rubber Gasket Gasket Only Diameter
No. Each Hose Size 5372 $14.95 493 $3.25 2"
5140 $93.85 3/4" 5373 23.15 332 3.80 3"
5141 93.85 1" 5374 35.00 259 3.80 4"
5142 57.10 1-1/4" 5375 40.00 396 4.90 5"
5143 93.85 1-1/2" 5376 117.50 5029 8.60 6"
For Replacement Zinc No. E1F — See Fig. 254 5068 1.15 Fiber Washer

Replacement Heat Exchangers

NOTE: Last Digit Available on Special Order ONLY.
5=Copper, 7=90/10 Cupro Nickel Allow approximately
Tube Bundles 1 to 2 weeks for delivery.
Typically Cupro Nickel outlasts Copper 50-100% FIG 2S/O

CHRIS CRAFT LEHMAN (continued) ONAN (continued)
Sen-Dure No. Each Chris Craft No. Sen-Dure No. Each Onan No. Sen-Dure No. Each Onan No.
1099-2-5 Ask 16.99-07434 10342-1-5 Ask 2C232 3976-2-5 Ask 130-2162
1051-1-5 Ask 16.99-07698 10342-1-7 Ask 2C239 11940-1-5 Ask 130-3506
1067-2-5 Ask 16.99-08003 10302-1-5 Ask 2C242 2518-1-5 Ask 130-1111
1375-2-5 Ask 16.99-08336 10302-1-7 Ask 2C240
2148-2-5 Ask 16.99-08763 10337-1-5 Ask 2C246 PERKINS
2196-4-5 Ask 16.99-08771 10337-1-7 Ask Cupro Nickel Sen-Dure No. Each Perkins No.
1273-2-5 Ask NA001402
CHRYSLER MERCEDES-BENZ 1273-2-7 Ask Cupro Nickel
Sen-Dure No. Each Chrysler No. Sen-Dure No. Each Mercedes No. 1383-5-5 Ask NA001405
K3570 Ask 2847886 1201-1-5 Ask OM636 1448-4-5 Ask NA001406
3394-1-5 Ask 3675141 1201-1-7 Ask Cupro Nickel 1396-3-5 Ask NA001407
2165-5-7 Ask 4142016 1814-3-5 Ask NA001545
MERCURY 1550-2-5 Ask NA001831
CRUSADER Sen-Dure No. Each Mercury No.
Sen-Dure No. Each Crusader No. 1580-6-5 Ask 63107 1550-3-5 Ask NA004490
9365-1-5 Ask 97434-5 1604-3-5 Ask 62472 2551-1-5 Ask NA001868
9365-1-7 Ask 97434-7
1695-1-5 Ask 61804 WESTERBEKE
9364-1-5 Ask 97433-5 2394-7-5 Ask 75959 Sen-Dure No. Each Westerbeke No.
9364-1-7 Ask 97433-7 2604-4-5 Ask 77319P 1380-1-5 Ask 11966 HEAT EXCHANGERS
KOHLER 2645-4-5 Ask 78165P 1279-3-5 Ask 12887
Sen-Dure No. Each Kohler No. 2826-1-5 Ask 79607P 3193-1-5 Ask 14129
1040-1-5 Ask 240779 4215-1-5 Ask 99438 1269-3-5 Ask 14156
1040-1-7 Ask 240779-7 1476-1-5 Ask 15065
ONAN
1056-1-5 Ask 266063 Sen-Dure No. Each Onan No. 2889-1-5* Ask 15799
1056-1-7 Ask 269058 2008-2-5 Ask 130-0904 1634-1-5 Ask 16455
1027-1-5 Ask 285430 1992-2-5 Ask 19058
1027-1-7 Ask 285430-7 2008-2-7 Ask Cupro Nickel 2334-2-5 Ask 20519
*Heat Exchanger ONLY, No Tank. 1816-5-5 Ask 130-0911 2729-3-5* Ask 21903
1816-5-7 Ask Cupro Nickel 2929-1-5* Ask 22406
LEHMAN 2644-3-7 Ask Cupro Nickel 3532-3-5 Ask 24308
Sen-Dure No. Each Lehman No. 1047-3-5 Ask 130-0629 3618-1-5 Ask 24774
1050-9-5 Ask 2C208 1047-3-7 Ask Cupro Nickel 3641-1-5 Ask 24819
1003-9-5 Ask 2C209 1435-2-7 Ask 130-0874 4281-1-5 Ask 32318
1262-9-5 Ask 2C211 3096-2-7 Ask Cupro Nickel 4664-1-5 Ask 32501
1342-9-5 Ask 2C213 1392-1-5 Ask 130C796 1296-3-5 Ask —
1050-9-7 Ask 2C216 3096-2-5 Ask 130-1394 3659-1-5 Ask —
1003-9-7 Ask 2C217 3207-2-7 Ask 130-1527 3661-1-5 Ask —
1262-9-7 Ask 2C218 4523-1-5 Ask 130-2536 *Original unit required for replacement.
1342-9-7 Ask 2C219 12189-1-7 Ask 130-2343
