480 Zincs

Donut Collars Shaft Collars

Stainless Nut Copper Contact
Cast In for Permanent
Ground
Copper Contact for
Permanent Ground
Screw Held in
FIG 253 by Washer
Per
No. Each Shaft OD Width Box FIG 252
C3 $20.10 1" 2-1/2" 1-1/4" 10
C5 20.10 1-1/4" 2-1/2" 1-1/4" 10 Zincs per box: X1-X5 (24), X6-X7 (12), X8-X9 (8), X10-X13 (4),
C7 24.35 1-1/2" 3" 1-1/4" 6 X15-X19 (2), D30-D100 (1).
C8 33.70 1-3/4" 3-1/2" 1-3/8" 5 No. Each Shaft Size No. Each Shaft Size
C10 42.90 2" 4" 1-1/2" 8 X1 $12.80 3/4" X15 $113.65 3-1/2"
C11 42.90 2-1/4" 4" 1-1/2" 8 X2 12.80 7/8" X17 137.15 4"
C12 58.80 2-1/2" 5" 1-1/2" 5 X3 14.05 1" X18 158.30 4-1/2"
C15 72.30 4" 6-1/2" 1-1/2" 4 X4 16.15 1-1/8" X19 172.85 5"
X5 16.60 1-1/4" D30 20.40 30mm
X6 21.40 1-3/8" D35 27.95 35mm
Prop Zincs For Maxi-Prop Propellers X7 21.40 1-1/2" D40 52.70 40mm
X8 33.95 1-3/4" D65 135.65 65mm
X9 35.23 2" D80 144.30 80mm
X10 74.85 2-1/4" D85 141.10 85mm
X11 72.60 2-1/2" D90 164.75 90mm
FIG 6009 X12 101.65 2-3/4" D100 150.20 100mm
X13 87.10 3"
For folding sailboat propellers.
Shaft Size Shaft Size Vetus Bow Thruster Anodes
No. Each inches millimeters For
63M-2 $11.65 3/4", 7/8", 22, 25, 28 2002 & Older 16/64"
1", 1-1/8" Propellers Hole
63M-3 11.65 3/4", 7/8", 22, 25, 28 2003 BP129 Diameter
1", 1-1/8" Propellers 1/4"
70M-2 16.75 1-1/4", 1-3/8" 30, 35 2002 & Older
Propellers 1-9/16"
70M-3 16.75 1-1/4", 1-3/8" 30, 35 2003
Propellers
63M 11.65 3/4", 7/8", 22, 25, 28 2001 & Older
1", 1-1/8" Propellers 43/64" 51/64"
70M 16.75 1-1/4", 1-3/8" 30, 35 2001 & Older
Propellers
83M 32.10 1-1/2", 1-3/4" 38, 40 –– BP195
63-70 5.15 3-pk. Metric Screws for 63M & 70M Zincs FIG 6016
83-100 6.05 3-pk. Metric Screws for 83M & 100M Zincs
N63-N70 5.15 3-pk. Metric Screws for 63M-3 & 70M-3 Fasteners are INCLUDED.
Each
No. $23.25
ZINCS Propeller Zincs and Brass Nut Kits BP195 38.20
BP129
Sea Strainer Zinc
Cross-Section View Measure for
Cast in Bronze Spacer Zinc shaft size arrow FIG 5182
to arrow
No. Each Length Width
SZ1 $9.20 3-7/8" 1-1/2"
Measure for thread size
arrow to arrow
Rudder Zincs
FIG 6008 Brass Bushing
for Permanent
Ground
The zincs for propeller nuts have a patent 259811. PN Nut Kit
contains 1 heavy-duty brass hex nut and 1 brass castle nut.
ZINC ONLY FIG 407
No. Each Shaft Thread Per
P3 $24.50 1" 3/4-10 No. Each Screw Length Diameter Box
P4 24.50 1-1/8" 3/4-10 R1 $5.20 3/4" 1-7/8" 25
P5 24.50 1-1/4" 7/8-9 R2 14.80 1-1/2" 2-13/16" 25
P7 33.70 1-1/2" 1-1/8-7 R3 21.15 1-1/2" 3-3/4" 20
BRASS NUT KIT ONLY R4 38.45 1-1/2" 5" 8
PN3 43.40 — 3/4-10 R4L 38.45 2" 5" 8
PN4 43.40 — 3/4-10 R5 56.55 2-1/4" 5-1/8" 6
PN7 97.20 — 1-1/8-7 R7 86.05 2-1/4" 6-1/2" 2
