Standard and Heavy-Duty Rudder Ports

2900-2904 2905-1-1/2M-OORP200

FIG 1088b

All are cast bronze. 2900 thru 2904 have square flanges. 2905-1-1/2M and OORP200 are heavy-duty and are rectangular.
Bearing
No. Each Shaft Flange Length
2900 $179.95 1" 3-1/2" x 3-1/2" 2-1/8"
2902 275.60 1-1/4" 4" x 4" 3-1/2"
2904 439.10 1-1/2" 4" x 4" 5-1/2"
2905-1-1/2M 701.30 1-1/2" 7" L x 4-1/8" W 9-1/4"
OORP200 797.75 2" 7" L x 4-1/8" W 9-1/4"
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Bronze Packing Boxes

Hex Spud Hex Nut Body Hose Section Clamp
Stainless Steel

Packing Shaft Packing
Box Size Size
PB100 1" 1/4"
PB125 1-1/4" 1/4"
PB138 1-3/8" 5/16"
PB150 1-1/2" 1/4"
PB175 1-3/4" 1/2"
PB200 2" 3/8"

FIG 672b STUFFING BOXES, ETC.

A complete assembly includes all parts shown (2 clamps). The nut, spud and body are finely machined cast bronze. Hose is 5-ply
marine exhaust hose. Clamp is all stainless steel up to and including 1-1/4" sizes. Larger sizes have heavy-duty malleable iron clamp
with rustproof plating.
Compl. Compl. Shaft Hose Hex Spud Hex Spud Hex Nut Hex Nut Hose Hose Clamp Clamp
No. Each Size I.D. No. Each No. Each No. Each No. Each
— — — — — — — — — — —
— — — — — — — — HO175 $18.50 Use No. 32H — See Fig. 3191
PB100 $135.45 1" 1-3/4" — — — — HO175 18.50 Use No. 32H — See Fig. 3191
— — — — — — — — HO175 18.50 Use No. 32H — See Fig. 3191
PB125 201.25 1-1/4" 2-1/4" — — — — HO225 18.75 Use No. 44H — See Fig. 3191
PB138 239.25 1-3/8" 2-1/2" — — 138PBN $20.45 HO250 24.30 —
PB150 225.95 1-1/2" 2-1/2" — — 150PBN 20.85 HO250 24.30 —
PB175 388.30 1-3/4" 3" — — — — HO300 39.45 —
PB200 400.25 2" 3" — — — — HO300 39.45 —
HO200 18.05 Use No. 36H — See Fig. 3191
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
For Flax Packing — See Fig. 3487 or Fig. 3440
