SIMRAD-YACHTING |

ECHOSOUNDERS ECHOSOUNDERS

Transducers and Modules
From all in one Active Imaging technology to the three-dimensional images of StructureScan® 3D,
we offer something for every angler, on any budget.

MAIN FE ATURE S
ACTIVE IMAGING™
Perfect for pinpointing fish-holding areas like rocks, reef, All of your sonar – CHIRP, SideScan and
weedbeds and wrecks. Active Imaging™ sonar DownScan – from a single transducer
delivers superior clarity and the highest
resolution images of fish and More refined detail and better range
structure at a longer range than than any other imaging technology
any other structure imaging Easier target identification with
technology.
FishReveal™ Smart Target View
Supports Medium and High CHIRP
(83/200kHz) + SideScan and DownScan
(455/800kHz)

Our clearest, sharpest sonar image ever Quickly identify fish-holding structure like Active Imaging™ doesn’t sacrifice range
without sacrificing any range. rocks, reef, weedbeds and wrecks. for image clarity, allowing you to find the
structure faster.

SONARHUB SOUNDER MODULE MAIN FE ATURE S

This all-in-one sounder solution combines StructureScan® HD imaging and CHIRP Advanced Simrad Broadband
sonar. SonarHub is ideal for marking fish and tracking lure action and can provide Sounder™ technology offers high
easy-to-understand views of structure and bottom performance with low noise
detail. Offering a powerful performance advantage
in any situation, SonarHub provides high-definition Simrad CHIRP technology works with
detail to depths of up to 1,000 metres (3,500 feet). traditional 50/83/200 kHz transducers
SonarHub’s StructureScan HD functionality gives
boaters picture-like displays for more productive Plug-and-play compatibility with
fishing, diving and search and recovery operations. Simrad and Airmar transducers
Three Ethernet ports for connection
to multiple Simrad displays
Dual ports: Connect one single-frequency or
CHIRP transducer, plus one StructureScan®
HD or ForwardScan™ transducer

Wreck strewn across seabed with fish Underwater truck wreck (showing the left
sitting on parts. hand side of a SideScan view)

22 | SIMRAD-YACHTING.COM
