StructureScan® 3D
StructureScan 3D imaging scans underwater terrain and fish-holding structure to create a
high-resolution, 180-degree, three-dimensional view beneath your vessel.

Water Leading
temperature Edge scanning
coverage

Fish sign holding Easy pan-tilt-
behind wharf rotate control
pilings

Zoom control

Vessel’s
centre line

StructureScan3D ScanTrack highlights wharf pilings as fish-holding structure

StructureScan3D showing fish-holding around rocky structure StructureScan3D’s ScanTrack view showing two distinct fish
near Nelson, New Zealand. Use Vertical Enhancement to make groups of varying species or size holding at different depth
smaller structure appear larger and more visible. contours against this drop off.

STRUCTURESCAN® 3D MAIN FE ATURE S
With this unique imaging view, anglers gain a better Unrivaled SideScan image clarity
understanding of where fish and structure are located
in relation to their vessel. StructureScan 3D imaging High Definition (HD) and super-wide 3D scanning
is available on Simrad NSS evo2, NSS evo3, NSO evo2
and NSO evo3 displays, when used in combination with Leading Edge™ Scanning Reference
the StructureScan 3D SelectScan™ target identification
module and 3D Skimmer®
transducer. Vertical Enhancement Control and Waypoint Overlay
ScanTrack™ pan-tilt-rotate controls
Enhanced SideScan Skimmer® transducer design
