BOW PRO DC-AC INDUCTION BOW AND STERN THRUSTERS
BOW PRO 48V thruster series (BOWA)
Tailor made for vessels with electric propulsion
Specifications BOW PRO BOW PRO BOW PRO
364 574 764
Product code BOWA0364 BOWA0574 BOWA0764
Thrust in N (kgf) (effective power output) 360 (36) 570 (57) 760 (76)
Power kW 1,6 3,1 3,1
Brushless induction motor
Tunnel diameter, internal, inches 4 /64 5 /32 7 /32
9
59
29
Weight excl. tunnel, in lbs 57 68 77
For DC Systems, Volt 48 48 48
Current consumption, Amps. 80 95 105
Operating time 10 10 10
- continuously at maximum thrust, in minutes
- at reduced thrust Endurance rated*
Main fuse ZE200 (200 Amps) ZE200 (200 Amps) ZE200 (200 Amps)
Batteries 12 Volt D.C., min. Ah 4 x 60 4 x 60 4 x 60
Battery main switch, model BATSW 100 150 150
* After 10 minutes full power, power may reduce. At less than full power setting, run time depends on battery capacity
BOW PRO BOOSTED thruster series (BOWB)
BOW PRO with benefits
The BOW PRO Boosted thruster series is innovative and completely different
compared to existing thrusters. All the features of the phenomenal BOW PRO with
a bonus! On the motor, a third connections is present. This leads the power to the
internal charger which boost the output up to double the voltage. In practice, this
means you are able to connect the 24 V BOW PRO Boosted to a 12 V power supply
and run it without any problems! Connecting the BOW PRO Boosted directly
to a 24 V power supply is also possible of course. The built-in charger recharges
your battery when the thruster is not in use, doubling the value of the BOW PRO
Boosted on board.
Battery advice of the BOW PRO (BOOSTED) series is slightly higher than the advice
for the conventional DC thrusters, as run time is decisive for these series. For
appropriate control controls please see our options at page 190.
Specifications BOW PRO BOW PRO BOW PRO BOW PRO BOW PRO BOW PRO BOW PRO
BOOSTED 57 BOOSTED 65 BOOSTED 76 BOOSTED 90 BOOSTED 110 BOOSTED 130 BOOSTED 150
Product code BOWB057 BOWB065 BOWB076 BOWB090 BOWB110 BOWB130 BOWB150
Thrust in N (kgf) (power output) 570 (57) 650 (65) 760 (76) 900 (90) 1100 (110) 1300 (130) 1500 (150)
Power kW 3,1 kW (24V) 3,1 kW (24V) 3,1 kW (24V) 5,7 kW (24V) 5,7 kW (24V) 5,7 kW (24V) 5,7 kW (24V)
Brushless induction motor
9
29
9
27
9
Tunnel diameter, internal, inches 5 /32 7 /32 7 /32 7 /32 7 /32 7 /32 9 /32
9
9
Weight excl. tunnel, in lbs 81.5 81.5 81.5 81.5 81.5 81.5 81.5
For DC Systems, Volt 12 / 24 12 / 24 12 / 24 12 / 24 12 / 24 12 / 24 12 / 24
Current consumption, Amps. 95 130 250 250 275 290 300
Operating time
- continuously at maximum thrust, 10 10 10 10 10 10 6
in minutes
- at reduced thrust Endurance rated*
ZE200 ZE300 ZE200 ZE200 ZE300 ZE300 ZE300
Main fuse
(200 Amps) (300 Amps) (200 Amps) (200 Amps) (300 Amps) (300 Amps) (300 Amps)
Batteries 12 Volt D.C., min. Ah 2 x 60 2 x 60 2 x 108 2 x 105 2 x 125 2 x 150 2 x 165
Battery main switch, model BATSW 250 250 250 250 250 250 250
* After the given runtime, power may reduce. At less than full power setting, run time depends on battery capacity
