RUDDERS

Rudder gland type HENKO

This bronze rudder gland is available in 2 different lengths for Ø 1 / 16’’ (30 mm)
3
9
or Ø 1 / 16’’ (40 mm) rudder stocks.

Type Ø D L A Ø B C C
57
9
3
HENKO30 1 /16” 6 /64” 19 /32” 2 /16” -
HENKO30L 7.9 gal. 10 /64” 19 /32” 2 /16” 5 /16”
5
9
53
HENKO40 1 /16” 8 /64” 43 /64” 3 /32” -
5
5
9
5
5
HENKO40L 10.5 gal. 12” 43 /64” 3 /32” 5 /16”
HENKO..L HENKO
REMOTE CONTROL STEERING
Follow-up steering
Suitable for boats of 18 ft. - 60 ft. (6 - 20 metres) LOA
Many pleasure craft are equipped with a manual hydraulic steering system. The VETUS follow-up steering system can be
added to enable remote control from any position on board without the need to mount and connect a steering wheel.
This greatly facilitates adding an inside steering station in a finished and furnished space. This system comes from a type of
steering that is in common use with professional waterways vessels. By simply turning the steering handle, the rudder will
follow the exact angle of the handle and by returning the handle to the mid-position, the rudder will return to
mid-ships. Manual steering can be resumed at any time by switching the system off. VETUS’ follow-up steering meets the
EMC requirements.

Type FUHANDLE with control box type FU1224
Steering from any convenient place on board!
The fixed control handle can operate any type of hydraulic steering system with an electro-hydraulic pump, by means of the
control box. It can be mounted on the dashboard or fixed to the helmsman’s seat. This type of remote control can be used as
the main steering device instead of the steering wheel, or as second or even third steering option.
Specifications
23
• Panel dimensions 4 / 16” x 4 / 32” (110 x 120 mm)
5
• Dimensions incl. handle 4 / 16” x 7 / 2” (110 x 190 mm)
5
1
• Height 1 / 4” (45 mm)
3
Type Description
FUHANDLE Dash mount control handle for follow-up system
FU1224 Control box for follow-up system, 12/24 Volt

FU1224

FUHANDLE

Creators of Boat Systems 257
