Accessories

Deck Gear ANCHORS • ROPE AND CHAIN

ROPE AND CHAIN
Maxwell can supply a full range of anchor rodes including chain-only,
rope only or a pre-spliced combination of rope and chain rodes. Chains
for vessels up to 100 metres (300 feet) and 8-plait (brait) nylon rope
for vessels up to 20 metres (65 feet) in length as well as ropes and
hawsers commonly used on superyachts.
Please see the pictures shown on this page for sizes and
characteristics.
STANDARD COMBINATION ROPE CHAIN KITS
CHAIN ROPE LENGTH
CHAIN Ø ROPE Ø
LENGTH 50 m 100 m 150 m 200 m
6 mm 10 mtrs 12 mm SP2627 SP2628 SP2629 SP2630
6 mm 20 mtrs 12 mm N/A SP2643 N/A N/A
8 mm 10 mtrs 14 mm SP2631 SP2632 SP2633 SP2634
8 mm 20 mtrs 14 mm SP2644 SP2642 N/A N/A
10 mm 10 mtrs 16 mm SP2648 SP2649 N/A N/A
NYLON 8 PLAIT ROPE
10 mm 20 mtrs 16 mm SP2645 SP2646 N/A N/A
12MM (SP3167) 14MM (SP3168)
Custom lengths available. Contact your Maxwell Dealer. 16MM (SP3169) 20MM (SP3170)

CHAIN SNUBBERS ANCHOR TENSIONER
Alternative method of taking the load of your Simple, easy to use and adjustable tensioner
windlass This innovative anchor tensioner secures the anchor firmly into the bow roller,
These snubbers are recommended to secure the anchor taking the weight off the windlass and preventing accidental deployment of the
while under way. Available in rope version with chain clevis anchor. The tensioner is suitable for use with 7 mm (¼”) to 12 mm (½”) short
hook. See picture below for the various sizes. link chain and can be secured to an existing cleat or bollard so no installation is
required.

(P105072)

6 MM (SP3174)
8 MM (SP3175)
10 MM (SP3176)

339
