COMFORT
Pedestal dimensions Hole pattern
Seat pedestals
D² R= 127
All pedestals are made of high grade aluminum and have a 360º H²
Ø
rotatable swivel on top. Gas adjustable pedestals are operated H¹ ØD1D1 ØT (for slides) 300
with a handle. Manually adjustable pedestals have both a lock- ØD2D2
Ø
pin with a locking position every 1” (25 mm) and a clamping D¹ H H S= 127
knob for complete security. The sliding mechanism can be moved W²
through 5 /16 (135 mm) in total and locked in one of 7 positions. ØD3D3 W¹ (for swivels) 127
5
Ø
Note
An explanation of the classification logo which is shown next to each
seat mount can be found on page 346 of this catalogue.

Gas adjustable pedestals with
slide
For optimum enjoyment of your seat. Gas spring
height adjustable aluminum seat pedestal with slide
and 360º swivel. Polished base.

Hole Pedestal Ø Base Ø Weight
Type Height (H)
pattern (D1 / D2) (D3) (lbs)
PCG3040 11 13 /16 - 15 3 /4 R / S 2 7 /8 / 3 27 /64 8 31 /32 13
PCG3547 13 25 /32 - 18 1 /4 R / S 2 7 /8 / 3 27 /64 12 1 /64 15.5
PCG4363 17 1 /8 - 23 13 /16 R / S 2 7 /8 / 3 27 /64 12 1 /64 17
PCG5680 22 1 /16 - 31 1 /2 R / S 2 7 /8 / 3 27 /64 12 1 /64 20
PCG3040 PCG3547 PCG4363 PCG5680

Manually adjustable pedestals
with slide
Manually height adjustable aluminum seat
pedestal with slide and 360º swivel. Polished
base.

Height Hole Pedestal Ø Base Ø Weight
Type
(H) pattern (D1 / D2) (D3) (lbs)
PCMS3040 11 13 /16 - 15 3 /4 R / S 2 7 /8 / 3 27 /64 8 31 /32 13
PCMS3547 13 25 /32 - 18 1 /4 R / S 2 7 /8 / 3 27 /64 12 1 /64 15.5
PCMS3040 PCMS3547 PCMS4363 PCMS4363 17 1 /8 - 63 /64 R / S 2 7 /8 / 3 27 /64 12 1 /64 17

Manually adjustable pedestals
without slide
Manually height adjustable aluminum seat
pedestal with 360º swivel only. Anodised base.

Height Hole Pedestal Ø Base Ø Weight
Type
(H) pattern (D1 / D2) (D3) (lbs)
PCM3040 11 13 /16 - 15 3 /4 S 2 23 /64 / 2 7 /8 8 31 /32 9
PCM3547 13 25 /32 - 18 1 /4 S 2 23 /64 / 2 7 /8 8 31 /32 6.5
PCM4363 17 1 /8 - 63 /64 S 2 23 /64 / 2 7 /8 8 31 /32 12.5

PCM3040 PCM3547 PCM4363

Dimensions in inches Creators of Boat Systems 355
