Page 358 - Vetus

COMFORT

Slide
Seat slide for direct mounting. The sliding mechanism can be
moved through 5 /16“(135 mm) in total and locked in one of
5
7 positions.
SCU Type Height (H) Hole pattern Base Weight (lbs)
SCU 2 3 /4 R + S S 4.5

Removable pedestal (fixed height)
With 360º swivel or slide and recessed anodised base. Base and
pedestal fit most commonly used similar systems in the market.

Swivel Hight Pedestal Base Recessed Hole
Type
(hole pattern) (H) Ø (D2) Ø (D3) depth Ø
PCR38 Swivel (S) 14 61 /64 2 23 /64 8 31 /32 2 3 /4 3 35 /64
PCRS38 Slide (R) 14 61 /64 2 23 /64 8 31 /32 2 3 /4 3 35 /64
PCR38 PCRS38

Removable pedestal
With 360º swivel and recessed anodised base. Base and pedestal fit
most commonly used similar systems in the market.

Swivel Hight Pedestal Base Recessed Hole
Type
(hole pattern) (H) Ø (D2) Ø (D3) depth Ø
PCRQ33 Quick position (S) 12 62 /64 2 23 /64 8 31 /32 2 3 /4 3 35 /64
PCRQ38 PCRQ38 Quick position (S) 14 61 /64 2 23 /64 8 31 /32 2 3 /4 3 35 /64

PCRQ33

PCRBASE
This (spare) plug-in pedestal base can be used as an extra mounting
position or as replacement for existing pedestal bases. The base is
made of a marine grade anodized aluminium.

PCRBASE

358 V-Quipment - Want to know more? Visit www.vetus.com Dimensions in inches
