OVERVIEW OF HOSES

Rubber exhaust hose type SLANG
Flexible and strong, saving valuable installation time
VETUS exhaust hose type SLANG is the most flexible hose because of the increased spiral
reinforcement and the extremely supple rubber. The completely smooth internal surface of
the hose will reduce back pressure in the engine. Exhaust hoses with an internal diameter
up to Ø 6’’ (152 mm) have a bending radius of 1,5 x the diameter. Exhaust hoses with an
internal diameter of more than Ø 152mm have a bending radius of twice the diameter.
Temperature resistant between - 22° and + 212°F (-30º + 100ºC)
with brief temperatures of 39°F (115°C ).

Type SLANG is approved by Lloyds Register and meets the
requirements of the SAE J2006 R2 standard. SLANG

1
3
An engine with a water injection exhaust elbow with an external diameter of 57 mm (2 /4”) may be connected to 2 /8” (60 mm) VETUS exhaust hose.
In this case VETUS waterlocks, mufflers, goosenecks and transom connections with a size of 2 /8” (60 mm) can be used as well.
3
HCS and HCHDS (heavy duty) clamps are made of stainless steel. For more information about hose clamps see page 386.

DWHOSE..B
Type Internal External Weight Max. pressure Bending HCHD(S) clamp HCS clamp Roll
Ø inches Ø inches kg/m bar radius to suit to suit length (m)
(mm) (mm) inches (mm)
DWHOSE10B 3 /8 (10) 5 /8 (16) 0,16 7 20 HCS12 30
DWHOSE12B 1 /2 (12) 11 /16 (18) 0,18 7 25 HCS12 HCS16 30
DWHOSE16B 5 /8 (16) 7 /8 (22) 0,24 6 35 HCS16 HCS20 30
DWHOSE19B 3 /4 (19) 1 (26) 0,32 5 50 HCS16 HCS20 HCS25 30
5
DWHOSE25B 1 (25) 1 /16 (33) 0,53 5 60 HCS25 HCS32 30
DWHOSE28B 1 /8 (28) 1 /16 (36) 0,57 4,5 66 HCHD(S)034 HCS25 HCS32 30
1
7
DWHOSE30B 1 /16 (30) 1 /2 (38) 0,60 4,5 70 HCHD(S)037 HCS25 HCS32 30
3
1
DWHOSE32B 1 /4 (32) 1 /16 (40) 0,56 4,5 75 HCHD(S)037 HCHD(S)040 HCS32 HCS40 30
1
9
DWHOSE35B 1 /8 (35) 1 /4 (44) 0,73 4 80 HCHD(S)043 HCS32 HCS40 30
3
3
DWHOSE38B 1 /2 (38) 1 /8 (47) 0,80 4 90 HCHD(S)043 HCHD(S)047 HCS32 HCS40 30
1
7
DWHOSE40B 1 /16 (40) 1 /16 (49) 0,87 3 95 HCHD(S)047 HCS32 HCS40 10
15
9
DWHOSE45B 1 /4 (45) 2 /16 (55) 1,10 3 105 HCHD(S)051 HCHD(S)055 HCS40 HCS50 10
3
3
DWHOSE50B 1 /16 (50) 2 /8 (60) 1,20 3 125 HCHD(S)059 HCS50 10
3
15
FUHOSE - FUHA - FHA115..A
Type Internal External Weight Max. pressure Bending HCHD(S) clamp HCS clamp Roll
Ø inches Ø inches kg/m bar radius to suit to suit length (m)
(mm) (mm) inches (mm)
FUHOSE06A 1 /4 (6) 1 /2 (13) 0,16 10 1 (25) HCS08 HCS12 30
FUHOSE08A /16 (8) 5 /8 (16) 0,24 10 1 /16 (30) HCS12 30
5
3
FUHOSE10A 3 /8 (10) 11 /16 (18) 0,28 10 1 /8 (35) HCS12 HCS16 30
3
FUHOSE13A 1 /2 (13) 7 /8 (22) 0,39 10 1 /16 (50) HCS16 HCS20 30
15
3
FUHOSE16A 5 /8 (16) 1 (25) 0,45 10 2 /8 (60) HCS16 HCS20 30
FUHOSE19A 3 /4 (19) 1 /8 (28) 0,52 10 3 /8 (80) HCS20 HCS25 30
1
1
FUHOSE25A 1 (25) 1 /8 (35) 0,73 10 4 /16 (110) HCHD(S)034 HCS25 HCS32 30
5
3
FUHA11506 1 /4 (6) 5 /8 (16) 0,22 17 1 /2 (13) HCS08 HCS12 30
FUHA11508 5 /16 (8) 11 /16 (17) 0,24 17 7 /8 (22) HCS12 30
FUHA11510 3 /8 (10) 11 /16 (18) 0,30 17 7 /8 (22) HCS12 HCS16 30
FUHA11513 1 /2 (13) 7 /8 (23) 0,38 17 1 /8 (35) HCS16 HCS20 30
3
FHA11506A 1 /4 (6) 5 /8 (15,6) 0,22 17,2 1 /2 (13) HCS8 76
FHA11508A /16 (8) 21 /32 (16,7) 0,24 17,2 7 /8 (22) HCS12 76
5
FHA11510A 3 /8 (10) 23 /32 (18,4) 0,30 17,2 7 /8 (22) HCS12 76
FHA11513A 1 /2 (13) 7 /8 (22,6) 0,38 12,1 1 /8 (35) HCS16 76
3
406 Want to know more? Visit www.vetus.com
