INDIREC T LIGHTING

LED ROPE LIGHT

Key Features & Benefits
• Flexible PVC tubing easily bends around tight corners
• Economical and easy to install
• 1" LED spacing provides consistent light coverage
• Typically used under cabinets, behind valances or under toe kicks

LED Colors*
Single Color: Warm, Cool, Red, Blue, Green
*Other colors available upon request
12V (WW,CW,B,G) 24V (WW,CW,B,G) 120V (WW,CW,R,B) LED Rope Light
1 YEAR

Specifications (LED Rope Light) 12V (Red) 24V (Red)
Beam angle (FWHM) Omni-directional
Power consumption .87W/ft .65W/ft .87W/ft .58W/ft .73W/ft
Luminous flux (lm)** 80lm/ft

Lifetime hours (70% light output) 10,000
Halogen equivalency 5W/ft
Input voltage 12VDC 12VDC 24VDC 24VDC 120VAC
Ingress protection (IP) IP65

12V (WW,CW,BL) 24V (WW,CW,BL 120V (WW,CW,R,B) Neon LED Rope Light

Specifications (Neon LED Rope Light)
Beam angle (FWHM) 160 O

Power consumption 2.44W/ft
Luminous flux (lm)** 85lm/ft
Lifetime hours (70% light output) 10,000 12V (WW,CW,BL) 24V (WW,CW,BL) 120V (WW,CW,R,B)
Dimensions
Halogen equivalency 10W/ft (Neon LED)
Input voltage 12VDC 24VDC 120VAC Dimensions 0.31"x 0.63" 7.8 x 16mm
Cut Length 3.30" 83mm 6.56" 167mm 19.7" 500mm
Ingress protection (IP) IP66 Max Run 33' 10m 66' 20m 164' 50m

** Luminous flux figures are for Warm White only. Cool White figures are available on our website (when Cool White is
an option).
Dimensions
(LED Rope) 12V (WW,CW,B,G) 12V (Red) 24V (WW,CW,B,G) 24V (Red) 120V (WW,CW,R,B)
Diameter 0.38" 9.5mm 0.38" 9.5mm 0.38" 9.5mm 0.38" 9.5mm 0.38" 9.5mm
Cut Length 3.00" 76mm 4.00" 102mm 6.00" 152mm 8.00" 203mm 36.00" 914mm
Max Run 32' 9.8m 32' 9.8m 65' 19.8m 65' 19.8m 328' 100m
