348 Oil and Fuel Pumps

U-Lube Oil Change Kit

FIG 1707

U-Lube Oil Change System is ideally suited to the task. Features a positive displacement gear pump that delivers up to
3 GPM, include touchpad control and dry-run protection, and has a re-settable breaker for over-current protection. Ports are 1/2"
female IPS. G6 is covered (except the valves). Dimension: 14.7" W X 6.9" D x 4.3" H.
No. Each Volts Breaker GPM Ports Description Weight
G6 $1058.00 12 DC 20 3 1/2" MIPS High-Flow – 6-Valve Oil Change Kit 14.3 lbs.
Diesel Fuel and Oil Transfer Pump
Reversible

Groco Vane Pump's vane impeller and blades
SPO are not affected by diesel fuel or crankcase oil.

PUMPING WATER PUMPING OIL
GPM GPM
Free Amps/ Flow Amps/
Flow Fuse Wire Size Free Fuse Wire Size
12V 7/15 17/30 #8 up to 40'
SPO60 24V 7.0 5/10 #12 up to 40' 4.5 8/15
OIL AND FUEL PUMPS SPO Self-Priming Pumps can be used for bilge pumping, (screened inlet) diesel fuel transfer or deckwash. The 60 Series is self-
Vane Pump
FIG 1709

priming to 24" and will pump more than 80' of head. Inlet and outlet ports are 1/2" female NPT an comes with two 1/2" male NPT x
3/4" GHT adaptors. Has a 316 stainless steel shaft. Dimensions: 4-1/2" H x 4" L. All SPO models feature ignition-protected ball bear-
ing motors. Do not pump gasoline or other explosive liquids. Weighs 7 lbs.
G.P.M.
Amps
Water/Oil
Volt
No.
Each
Heavy-Duty Reversible Pump
7/4.5
$641.00
7/17
12
SPO60R12
Heavy-Duty Reversible Pump
SPO60R24
7/4.5
651.00
5/8
24
SPARE PARTS Water/Oil Description
No. Each Volts/Description Fits System/Pump Model
Fig. 7787 No. 2-034 $2.50 Cover O-Ring SPO after s/n 1088, SPO60 & 80
Fig. 7787 No. SP99 10.00 Set Blades (4 to Set) All SP & SPO Series
Marine Fuel Pump
For Diesel, Gas and Alcohol Blends
FIG 2055b
Corrosion-resistant with a positive or negative ground. This pump has a minimum flow
rate of 43 GPH. It requires an external ground for gasoline applications, draws 2.3 Amps
and conforms to US Coast Guard regulation and UL-listings Weight: 5 lbs.
No. Each Ports IPS PSI Amps Volts
FRB13-2 $242.40 1/4"-18 6 to 11 lbs. 2.3 12 DC
FRB16-2 248.50 1/4"-18 6 to 11 lbs. 2.3 24 DC
For Required Pressure Switch No. 230-604B — See Fig. 7405
