General Purpose Pumps 353

Bronze Motor Pump Unit Bronze Motor Pump

WARNING!
6050-0003
MOTOR CAN SPARK EXPLOSION
AND DEATH CAN OCCUR.
DO NOT USE WHERE FLAMMABLE
VAPORS ARE PRESENT.

11810-0003

FIG 4846
FIG 3178
Made of all bronze construction with a rubber impeller for gen-
Self-primes instantly up to 10' dry impeller and 22' wet eral marine use. 1 HP motor rated at 1750 RPM, 115V or 230V
impeller. Has a bronze pump head suitable for many marine AC. Pumps 20 GPM with a 15 to 20-ft. lift (when impeller is
oriented jobs. Cap has overload protection on its continuous wet). Inlet and discharge are internally threaded for 1" IPS or
duty motors. A 8-ft. cord and carrying handle INCLUDED. slip fit 1-1/2" ID hose externally. A vacuum switch is included
Not ignition protected. 6050-0003 weighs 35 lbs.; 11810- for automatic cut-off when pump runs dry. Maximum PSI is 43
0003 weighs 22 lbs. Both pumps have ODP (open, drip- lbs. Pump weighs 39 lbs. Not Ignition-Protected.
proof) motors. No. Each Volts AC GPM
PUMPS 405MK4N26 $1368.00 115/230 25
Female AC GMP @ 10' Fig. 4669 No. 7046 215.05 Spare Vacuum Switch
No. Each IPS Volts Head
6050-0003 $973.30 1" 115/230 23 Run-Dry Utility Puppy Pump
11810-0003 948.10 1/2"* 115 9.5
*Also 3/4" Male Garden Hose Thread
Fig. 1JAB No. 90058-0003 203.05 Service Kit for 6050-0003
Fig. 1JAB No. 90105-0003 155.60 Service Kit for 11810-0003
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
Cyclone™ Stainless Steel
Centrifugal Pump GENERAL PURPOSE PUMPS

FIG 9938

Heavy-duty, high performance versions of the proven Water
Puppy pump but with an integral water reservoir at the dis-
charge port to protect the impeller from being damaged after
FIG 3121 the water supply to the pump is depleted. This feature allows
the pump to run-dry for up to 10 minutes. Ideal for bilge
pumping, emptying livewells or general fluid transfer where
This 316 stainless steel pump is designed to pump diesel, mild continuous monitoring of the pumping procedure is not practi-
chemicals and hot water. Ideal for deck washing. It has a cal. Both models have 3/4" IPS ports.
2,500-hour long motor life, rotatable head and anti-clog @10'
impeller. Ports: 3/4 IPS. Intermittent-duty pump. Suction Head Wt. DC
@10' Head No. Each Amps Lift GPM Lbs. Volts
No. Each Volts Amps GPM 23920-9423 $357.55 13 to 4 ft. 8 7-1/4 12
50860-0012 $451.35 12V DC 25 9 23920-9523 390.55 7.5 to 8 ft. 8 7-1/4 24
50860-0024 461.15 24V DC 15 9 Fig. 1728 No. 6303-0003 32.40 Impeller for 23920-9423 & 9523
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
For Jabsco Parts — See Pages 298-307
For Oberdorfer Parts — See Page 313-314
