474 Rudder Accessories

Swivel Socket

FIG 8723

Made of marine grade cast bronze. Use with ball type steering tiller arms.
Tapered For
No. Each Pipe Size Description
SWS75 $145.10 3/4" Socket
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Rudder Support Bearings Bronze Collars

FIG 1086
FIG 815

The cast bronze rudder support bearings and safety collar work
together to support stress and weight in inboard rudder installa- No. Each Shaft Size
tions. This bearing holds the top of the rudder post steady, main- RC100 $42.40 1"
taining alignment and reducing leverage stress on the rudder box. RC125 45.50 1-1/4"
No. Each Description RC150 43.70 1-1/2"
1 $81.55 1" Rudder Support Bearing RC175 109.30 1-3/4"
125 99.97 1-1/4" Rudder Support Bearing RC200 78.90 2"
15 142.60 1-1/2" Rudder Support Bearing WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

RUDDER ACCESSORIES TA100 CL50
Tiller Arms and Clevises

FIG 865

Tiller arms are manganese bronze with a 1/4" keyway and a stainless steel set screw. They are not pre-drilled for clevis pins. Clevises
are cast bronze and assembled with a 1/2" pin.
No. Each Shaft Size Length Description
TA100 $113.85 1" 9-1/2" Tiller Arm
TA125 119.80 1-1/4" 9-1/2" Tiller Arm
TA150 248.50 1-1/2" 15-3/4" Tiller Arm
CLEVISES
Female IPS Between Pin
No. Each Thread Length Jaw Size Diam.
CL50 $43.20 1/2" 3-1/2" 3/4" 1/2"
CL75E 57.95 3/4" 4-1/4" 5/8" 1/2"
