552 Horns

Full Blast Air Horns Electrical Trumpet Horns

10029XLP
and
10018XLP

10028XL

FIG 6526

Top of the AFI line and the most widely acclaimed marine trum-
pet horns. Manufactured from non-corrosive stainless steel for
FIG 9348 long lasting beauty. A sealed sound unit with stainless steel
diaphragm and vibration dampening mounting base. Has 18-8
stainless steel trumpet tubes. Prewired. Dimensions: 10028XL –
These compressor-driven air horns are the loudest, broadest 16-1/2" L x 4" W x 4-3/4" H. 10018XLP and 10029XLP – 18-1/2" L
line of 12V air horns available today. All of our horns produce x 8" W x 5" H. For vessels up to 12 meters.
sound levels ranging between 120 and 127db. Corrosion-resis- No. Each Meter Volts Amps Type
tant brass construction with white epoxy-coated finish. 10018XLP $299.10 123 24 DC 5 Twin
No. $470.50 Type Volts 17" L x 7" W x 3-3/4" H 10028XLP 142.45 118 12 DC 10 Single
Size
Each
10029XLP
12 DC
10
122
Twin
274.10
Twin
10122
12
HORNS Compact Electrical Trumpet Horns

10010 10011

FIG 6525

No. 10010 is recommended for saltwater use. 100% stainless steel exterior with its stainless steel diaphragm will give you a full
trumpet sound and the compact size is ideal for runabouts and other small crafts. Weighs 24.8 ounces and INCLUDES one mounting
bracket. Draws 3.5 Amps and 106 db @ 1 meter, for vessels up to 12 meters. No.10011 All stainless steel 12" and 14" trumpets.
INCLUDES mounting bracket and pad. Overall dimensions are 16" L x 7-1/2" W x 4" H. Horn button NOT included. Draws 7 Amps and
109 db @ 1 meter for vessels up to 12 meters.
No. Each Volts Size Type
10010 $123.30 12 DC 14"L x 3-1/2"W x 4"H Single
10011 242.75 12 DC 16"L x 7-1/2"W x 4"H Twin
For Horn Button — See Fig. 275
Horns are Coast Guard approved upon inspection when properly installed.
