RX Horizontal Windlass

The RX offers a maximum pull of 775kg, offering great performance and value for the 30ft to 48ft market range. Designed as a
discreet and compact unit, the RX is intended for use in confi ned chain lockers, where installation contraints prevent the use of a
conventional horizontal unit.
▪ 4 hybrid gypsy options: 6/7mm (1/4’’), 8mm (5/16”), 10mm DIN and 10mm ISO

▪ Stylish stainless steel and composite construction
▪ Motor gearbox outside sperate to the chain locker to prevent water ingress
▪ IP67 Ingress protection as standard

▪ Motor gearbox can be rotated for 360 ̊mounting

The specifi c angle of chain rode approach = Horizontal to -5 ̊

RX Specifications
NORMAL
MOTOR CURRENT CIRCUIT APPROX WEIGHT APPROX WEIGHT
MODEL POWER VOLTAGE MAX PULL WORKING LOAD LIMIT MAX LINE SPEED DRAW BREAKER GO GD
    / /      
   . .
   . .
 +   . .
 +   . .
   . .
   . .
Windlass performance values are tested using -/+10% 12 voltage simulating the operation parameters of an installed battery system of a boat
