G uardrails

Lewmar Guardrails are designed to protect the compass and pedestal with also
providing assistance while moving about the cockpit. Our wide range of straight,
kickback and extended guardrails, are manufactured from 32mm/1.25" heavy
duty 316 stainless steel tube. The extensive choice of guardrails is complemented
by our instrument pod range.

Enguard Guardrail kits
Enguard Guardrail Kits include: Guardrail (straight, kickback or extended kickback),
Engine Pod, Top Plate & Cup holder
