1. Windlasses

HX1 Horizontal Windlass

The HX range utilises a cast alloy and composite casing combined with a high-power drive train - using the latest inline motors
and epicyclical gearboxes - resulting in a strong reliable design. HX features a strong and durable anodized aluminium chassis
resulting in a strong, reliable design.

▪ Motor range 500W & 800W in 12V
▪ High efficiency epicyclical gearbox
▪ Sealed waterproof unit requires minimum maintenance

▪ Anodized aluminium chassis with a durable polymer cover
▪ IP67 rated as standard

▪ Quiet operation
▪ 2 gypsy models available to suit calibrated chain: 6/7mm (1/4"), 8mm

HX1 Specifications
NORMAL
CURRENT CIRCUIT APPROX WEIGHT APPROX WEIGHT
MODEL MAX PULL WORKING LOAD LIMIT MAX LINE SPEED DRAW BREAKER GO GD
    / /      
 .
 .

Windlass performance values are tested using -/+10% 12 voltage simulating the operation parameters of an installed battery system of a boat

38/39
