1. Windlasses

Pro-Series + Pro-Fish Horizontal Windlasses

The Pro-Series Windlass is the ideal horizontal unit for on-deck installation. A beautiful stainless steel case combines robustness
and strength. On the Pro-Fish edition, the automatic freefall mechanism means access to the windlass is not required to drop or
retrieve anchor The gypsy has been specially designed to suit leaded lines up to 16mm in diameter and an optimised control arm.
The new Pro-Guard plate prevents the rope from jumping out of the windlass or snagging during operation

▪ All stainless design

▪ Automatic freefall mechanism (Pro-Fish only)
▪ Manual emergency recovery equipped – all you need is a common 1/2" socket wrench

▪ Maximum pulling power: 320kg (700 lb) for the
700 and 454kg (1,000 lb) for the 1000

▪ 5-year warranty
▪ For boats up to 12m (38ft)
▪ Free Fall conversion kits
▪ DIY ready

Pro-Fish Features
▪ Redesigned control arm features higher spring tension
and modified profile to improve performance
▪ Closed cell neoprene gasket protects internals
▪ Unique Pro-Guard feature prevents rope jump and snags

▪ New gypsy designed specifically for up to 16mm leaded
anchor rodes
Pro-Series/Fish Specifications

NORMAL
MOTOR MOTOR MAXIMUM WORKING MAXIMUM CURRENT CIRCUIT
MODEL MAX.CHAIN SUPPLY POWER PULL LOAD LIMIT LINE SPEED DRAW BREAKER WEIGHT
        / /    
- ¹/₄ .
- ⁵/₁₆ .
- ¹/₄ .
- ⁵/₁₆ .
