ACCESSORIES

Battery selector switch type ACCUSCH
Famous for its multifunctional use
From the OFF position, in accordance with the switch pattern, battery 1 only, battery 1 plus battery 2 or
battery 2 only can be switched on. The switch enables usage and charging of the batteries individually
and in parallel connection. The switch has a red locking button which indicates and locks the switch
position, discouraging enthusiastic operation. Even though the battery selector is fitted, you still
have the choice which battery will supply which service. If your chosen battery is nearly discharged
or defective, the other battery can be called to the rescue. By using a VETUS battery selector switch,
the starter and domestic battery can be used and charged as you desire. The switch will “make before
break” and so battery selection is possible even with the engine running (do not go through the “Off”
position).
Specifications ACCUSCH
• Capacity at 6, 12, 24 or 32 Volt
• Continuous 175A / interval 300A
• Dimensions 5 / 16“ x 5 / 16“ x 2 / 64” (135x135x75 mm).
61
5
5
Type Description
ACCUSCH Battery selector switch

one engine - two batteries two engines - two batteries

Battery main switches type BATSW
Twin pole switching
May be connected to either the positive or the negative electric cable. Two positions: “ON”and “OFF”. In the “OFF”position the key
may be removed (except models 150 and 600). Provided with two M10 connectors. Model 250T is a twin pole switch to make/break
both the positive and negative cables. Model 600 is watertight according to IP 67.

BATSW075 BATSW100 BATSW150

BATSW250 BATSW250T BATSW600

BATSW150R*
Type BATSW075 BATSW100 BATSW250 BATSW250T BATSW600
BATSW150B**
Nominal operational (V) max. 24 max. 24 max. 24 max. 24 max. 48 max. 24

Current max.:
- Continuous operation 75 A 100 A 150 A 250 A 2 x 250 A 450 A
- 3 minutes’ load 800 A
- 5 seconds’ load 350 A 500 A 1000 A 2500 A 2 x 2500 A 3500 A

* BATSW150R = with red handle
**BATSW150B = with black handle
