BATTERIES

VETUS Deep Cycle battery
This type of deep cycle battery is ideal for applications such as electric propulsion.
The VEDC110TC is a group 31 “Deep Cycle / Semi-traction” battery featuring two different
connections. One set of conventional tapered battery clamp connections and one set of
threaded connection (5/16“) for cable lugs. Thicker plates inside the battery allow deeper
discharging (up to 75%) compared to conventional batteries and can be used for cyclic
applications. Because of this, the battery is very suitable for electric boating where the
battery is discharged over a longer period of time. The VEDC110TC battery is based on a
Sealed Maintenance Free battery, so the same battery chargers are applicable.

Specifications VEDC110TC
Type
Voltage 12 V
Capacity C20 110 Ah
Specifications
Capacity C5 90 Ah
• Suitable for heavy use over a longer period of time
Cold Cranking Amps CCA (EN) 800 A • Two different connections
Reserve capacity in minutes at 25A 200 • Thicker battery plates
• Dischargeable up to 75%
Dimensions LxBxH 330x175x240
• Compact
Weight (kg) 25,3 • Very suitable for electric propulsion or as a service battery
BATBOX L • Manufactured in the EU

Battery selection chart
SMF AGM VEDC110TC
Application Marine Battery Marine Battery Marine Battery
Engine starting   
Generator starting   
Bow thruster   
Anchor windlass   
Pumps   
Use with inverter   
Refrigeration   
Air conditioning   
Lighting   
Electric propulsion   
 - Not recommended  - Suitable  - Recommended  - Highly recommended
Battery selection chart
SMF Marine Battery AGM Marine Battery VEDC110TC Marine Battery
General
Maintenance free   
Deep discharge -  
Typical life span 5-6 years 6-8 years 5-6 years
Number of cycles - %age discharge 350 - 35% 500 - 75% +400 - 75%
Self discharge < 3% per month < 3% per month < 3% per month
Electrolyte Wet acid Absorbed glass mat Wet acid
Plate materials Lead - calcium Lead - calcium Lead - calcium
VRLA (pressure relief vent) -  -
Series connection allowed   
Parallel connection allowed   
Safe transportation -  -
Maximum angle in use 55° 55° 55°
Maximum installation angle 0° 0° 0°
Charging with standard charger   
