AUTOMATIC CHANGE-OVER DEVICE

Type IVPS
Constantly monitoring voltage range and power supply
If the power from the shore supply is disconnected or the generator output falls
outside the 180-250 Volt range, this change-over device will automatically switch in the
inverter. When both sources are available, the generator is given priority.
When switching to the generator, a time lapse of 0 up to 30 seconds can be set.
Specifications
• Capacity 4.5 kVA
3
3
• Dimensions 11 / 8’’ x 7” x 3 / 4’’ (290 x 180 x 95 mm)
• Weight 5.2 lbs (2.4 kg)
• Nominal voltage 230 Volt AC, 50Hz
IVPS

Shore power protector type SPP
Protection against overload of shore supply
Shore power protector with LCD display and connection cable (2 mtr) provides a warning when the shore supply is
overloaded. It will disconnect the overload before the breaker in the marina does. The shore power protector will not be
affected by equipment with a high inrush current such a refrigerator or air conditioning.
Specifications
• Input voltage 195 to 253 Volt AC / 50-60Hz
• Power consumption 5 Watt nominal
• Switch-off current 16A max. (user settable)
• Maximum switching power 3680 Watt resistive and weak inductive loads /
1500 Watt inductive loads at cos phi < 0,4 SPP230
• Operation within the limits of B- or C-fuse characteristics, temperature 0-104ºF (0-40ºC)

Solar charger type SL
Eco-friendly charging
The VETUS Solar Charger enables regulated battery charging when using solar panels. In addition to its charging function
this unit ensures that, when the batteries are fully charged, the output of the solar panels can be used for other purposes
(diversion regulation). In order to prevent complete discharge of the battery, the charging control function will disconnect
any consumers when the battery voltage drops too low. The VETUS Solar Charger may be used as a stand alone unit, or in
combination with the VETUS Combi-γ unit. In this case the Combi-γ will control the complete current supply. To allow the
solar charger to communicate with the Vetus Combi, please use the special 10 core connection cable RJ4510xx. Up to 10 Solar
Chargers may be connected in parallel formation.

The Solar Charger is protected against
• Short circuit
• Current overload from solar panel
• Reversed battery polarity
• Excess temperature

Solar Charger, type SL45 SL60
Maximum charging current 45 A 60 A
Charging characteristics 4-stage
Battery voltage 12-48 V
Maximum voltage of solar panel 125 V
Minimum voltage of solar panel 9 V
Ambient temperature During storage: -67ºF to +185ºF - During use: -40°F to +113°F
Relative humidity Max. 95%, condensation-free (p.c.b. is coated)
Dimensions (H x W x D) in inches (mm) 10 /2 x 5 x 3 (266 x 127 x 75) SL
1
Weight lbs (kg) 3.3 (1.5)

Creators of Boat Systems 231
