PORTHOLES

Portholes (AI)
Heavy duty portholes
These portholes are suitable for use in the hull side. The /8” (10 mm) ‘smoke’ coloured opening pane is set in a satin
3
anodised aluminium frame. Black or white powder coated frames are optional. The clamp fixing ensures that no fasteners
are visible from either inside or outside. The portholes can be held open in any position due to the friction type hinges.
In the closed position knobs ensure complete water tightness. The porthole can be fitted in a surface with a minimum
thickness of /16” (2 mm) and a maximum thickness of /16” (18 mm). As standard a mosquito screen is supplied. A fixed
11
1
version of each opening porthole is also available to special order.
Type PM (AI)
External dimensions Cut-out dimensions Cut-out radius
Type A x B C x D R Type mosquito
screen
inches (mm) inches (mm) inches (mm)
PM111 9 /64 x 5 /4 (244 x 146) 8 /32 x 4 /64 (220 x 122) 2 /32 (61) HOR11
51
21
3
13
39
PM121 11 /64 x 6 /64 (294 x 172) 10 /8 x 5 /64 (270 x 148) 2 /32 (74) HOR12
37
53
29
49
5
PM131 13 /32 x 7 /64 (344 x 198) 12 /32 x 6 /32 (320 x 174) 3 /64 (87) HOR13
27
51
27
19
17
PM141 4 /4 x 5 /4 (362 x 146) 13 /16 x 4 /64 (338 x 122) 2 /32 (61) HOR14
13
51
3
1
5
PM151 15 /64 x 8 /32 (390 x 220) 14 /32 x 7 /32 (366 x 196) 3 /64 (98) HOR15
23
13
21
23
55
PM161 15 /64 x 7 /64 (399 x 199) 14 /4 x 6 /64 (375 x 175) 3 /64 (87) HOR16
57
53
45
3
27
PM
Type PZ (AI)
External dimensions Cut-out dimensions Cut-out radius
Type A x B C x D R Type mosquito
screen
inches (mm) inches (mm) inches (mm)
PZ611 11 /32 x 6 /64 (301 x 164) 10 /32 x 5 /64 (277 x 140) 2 /8 (54) HOR61
29
33
29
27
1
PZ621 14 /64 x 7 /64 (368 x 179) 13 /64 x 6 /64 (344 x 155) 2 /32 (61) HOR62
35
3
13
31
7
13
3
13
31
35
PZ631 24 /64 x 7 /4 (622 x 197) 23 /64 x 6 /16 (598 x 173) 2 /32 (61) HOR63
PZ641 15 /8 x 7 /4 (397 x 197) 14 /16 x 6 /16 (373 x 173) 2 /32 (61) HOR64
5
13
3
11
13
PZ651 15 /64 x 7 /64 (399 x 190) 14 /64 x 6 /32 (375 x 166) 2 /8 (54) HOR65
1
17
31
49
45
PZ661 15 /64 x 9 /32 (399 x 234) 14 /64 x 8 /64 (375 x 210) 2 /8 (54) HOR66
1
45
7
17
49
27
PZ671 17 /4 x 10 /32 (451 x 274) 16 /16 x 9 /32 (427 x 250) 2 /8 (54) HOR67
1
25
13
3
A
C
R D B
Buitenmaten PZ611 PZ621 PZ631 PZ641 PZ651 PZ661 PZ671
in mm PZ613 PZ623 PZ633 PZ643 PZ653 PZ663 PZ673
A 301 368 622 397 399 399 451
PZ Inbouwmaten 164 163 197 197 190 234 274
B
in mm
Datum / Date
D C 277 140 344 139 598 173 373 173 375 166 375 210 427 250 Tek.Nr. # Titel / Dwg.no. # Title Wijziging / Revision Initialen / Initials
14109 - Main assembly - PZ661 - Catalogus
Inbouw
radius in mm Artikel code: Default Gewicht: 2794.82 gr Scale: Schaal: 1:2 Drawn: Get.: Proj.: Proj.: Gecontr.: Checked: A
Item code:
Weight:
Material:
Materiaal:
R 54 61 61 61 54 54 54 vetus Datum: Date: Size: Formaat: Custom Dim. in: Maten in: mm
FOKKERSTRAAT 571 - 3125 BD SCHIEDAM - HOLLAND Blad: 1 van: 1 VE title block R1.4
Sheet:
TEL.: +31 (10) - 4377700 FAX: +31 (10) - 4372673 E-mail: research@vetus.nl
