ESCAPE AND VENTILATION HATCHES

Type PLANUS (AII)
Stylish budget model
These hatches have a satin sheen anodised aluminium frame with a 3” (75 mm)
corner radius and a /8” (10 mm) ‘dark smoke’ coloured acrylic lid. A friction hinge
3
allows the hatches to remain open at any angle up to 180º.
Type PLANUS is suitable for design category A, Area II.

14
31 20
34
PLA
Maximum height (incl. dogs)

Escape hatches
External dimensions Cut-out dimensions Number of
Type
A x B inches (mm) C x D inches (mm) handles
PLA50L 20 /2 x 20 /2 (521 x 521) 18 /16 x 18 /16 (471 x 471) 2
1
1
9
9
PLA45L 18 /16 x 18 /16 (474 x 474) 16 /16 x 16 /16 (424 x 424) 2
11
11
11
11
A
Ventilation hatches C
External dimensions Cut-out dimensions Number of
Type
A x B inches (mm) C x D inches (mm) handles
PLA34L 15 /8 x 10 /4 (390 x 260) 13 /8 x 8 /4 (340 x 210) 1 R 75
1
3
1
3
1
3
1
PLA30L 13 /4 x 11 (350 x 280) 8 /4 x 9 /16 (300 x 230) 1
PLA23L 11 x 11 (280 x 280) 9 /16 x 9 /16 (230 x 230) 1
1
1
D B
Deck hatches
External dimensions Cut-out dimensions Number of
Type
A x B inches (mm) C x D inches (mm) handles
PLA40L 16 /16 x 16 /16 (424 x 424) 14 /4 x 14 /4 (374 x 374) 2
11
11
3
3
PLA32L 18 /16 x 13 /16 (474 x 344) 16 /16 x 11 /16 (424 x 294) 2
9
11
9
11
VETUS handles
Specifications
• The hatch can be opened from the inside or outside
• Can be locked or secured with an air gap for permanent ventilation
• An internal locking mechanism prevents opening from the outside when the boat is unattended
• The low external profiles ensures that ropes cannot get caught under the handles
OPEN
Type Description Colour
HLLRBG Hatch locks for all hatches Black
HLLRBG
CLOSED
