ACCESSORIES

Screen washer
Suitable for all VETUS wiper types
This screen washer is fed by a pressurised, potable water system. The screen washer comes with a hose, solenoid valve
(12 or 24 Volt D.C.) and switch, hose pillars, spray nozzles and skin fittings and is easy to install.

Type Description Voltage (V)
HDS12B Screen washer kit 12
HDS24B Screen washer kit 24
HDSXTB Extension screen washer kit for additional windscreen HDS

Type WPANEL in combination with rain sensor type MARBO

Completely pre-wired motor wipe panel
Type WPANEL can control up to 5 wiper motors to run synchronously at high or low
speed. Each wiper motor is individually switched, so you can select which wipers are
operational. They also feature a combination switch for screen wash/wipe activation,
speed selection and interval wipe delay. The wiper motors to be connected must have
a 2 speed motor and an automatic parking position. It is optional to connect up to
3 MARBO rain sensors to the control unit. The rain sensor function can be activated
by the supplied switch panel and can activate all 5 wipers simultaneously.
Type WPANEL is supplied with
• 1 control unit with electronic overload protection (can be DIN rail mounted)
• 5 wiper motor switches
• 1 combined switch for wash/wipe and speed selection
• 1 mounting plate with room for 6 switches and 2 blind plates

Specifications WPANEL
• Available for 12 or 24 Volt D.C. supply
• Power consumption in stand-by mode approx. 10 mA
• Maximum power per wiper motor 120 W
• Internal fuses 10 A each wiper motor, 5 A for screen wash pump or solenoid valve
• Dimensions control panel 1 /16” x /16” x 1 /32” (49 x 24 x 37,5 mm), control unit
15
15
15
1
9
5
6 /4” x 3 /16” x 2 /16” (159 x 90 x 58 mm)

Automatic rain-sensor for wiper activation

MARBO MARBO2

Type Specifications
MARBO Rain sensor incl. switch, 12/24 Volt
MARBO2 Additional rain sensor, 12/24 Volt
WPANEL Windscreen wiper control panel for up to 5 wipers, 12/24 Volt, incl. switches

Creators of Boat Systems 285
