Indicator Lights 159

Red Indicator Light Red Indicator Light

FIG 6087
17/32"
Can be used as a visual warning of engine problem or
switches in "On" position. Programmed for either gauges
or switches. Has plastic light lens cover with 6" wire leads.
12-Volt bulb INCLUDED.
Lens Bezel
No. Each Size Color Color Std. Pkg.
7/8"
IA62840 $10.15 1/2" Red Silver 10
LED Panel Lights

FIG 3027
COLE HERSEE INDICATOR LIGHTS
Smooth lens with bright, chrome-plated brass bezel. Has a
brass socket and a brass mounting bushing that is 3/4" in
diameter and 1-1/6" long. Additional ground wire permits
mounting in insulated panels. This light is self-grounding in
metal panels. Will mount in a maximum panel thickness of
7/8". Wire leads are 8" long. 12-Volt bulb INCLUDED. 305 Series
No. Each Lens Color Std. Pkg.
M320RC $25.10 Red 10
For 12V Bulb No. 53 — See Fig. 3043
LED Pilot Light

12/24 Series

FIG 9536b

LED Panel Lights are great for panel displays. 210° wide angle
viewing. Flanged, black nylon body provides ribs for snap-in
front panel mounting. Wire leads are 6" long. Only draws 15ma.
FIG 3037 Hole Std.
COLE HERSEE No. Each Color Volts Diam. Pkg.
305R $3.70 Red 12 DC 1/8" 25
These LED lights have a chrome-plated body, bezel, washer and 305G 3.70 Green 12 DC 1/8" 25
hexnut. The bezel protects LED from damage and reflects more 305R-24V 6.15 Red 24 DC 1/8" 25
light. Mounting hole is 17/32" diam. Body length: 1-1/4" and 305G-24V 7.15 Green 24 DC 1/8" 25
INCLUDES (2) 1/4" polarized terminals. Fits panels 3/64"-9/32". 12R 3.70 Red 12 DC 1/4" 25
No. Each Lens Color Volt 12G 3.70 Green 12 DC 1/4" 25
612R $9.10 Red 12 DC 24R 3.70 Red 24 DC 1/4" 25
612G 9.25 Green 12 DC 24G 3.70 Green 24 DC 1/4" 25
