Type "C" Countersinks, Stop Collars and Taper Point Drill Bits
82° Included Angle

Adjustable up
and down drill
for different
length screws.
Can also be
furnished with
Stop Collar to
FIG 6475 FIG 6477 FIG 6476 control depth.

Countersink Taper Point Stop Collar
Drill Bits

Fig. 6475 Countersinks are mounted on the Taper Point Drill Bit. Drills a hole for the threaded and shank portion of a screw.
Countersinks for bevel under screw head and counterbores for wood plugs over head of screw. Fig. 6477 Taper Point Drill Bits are
used to cut wood and plastic in one operation for thread and shank of wood screws. Fits all types of countersinks and counterbores.
Fig. 6476 Stop Collar will control depth of cut. Sizes are all in inches.
ALL MUST BE ORDERED SEPARATELY
Fig. 6475 Fig. 6477 Fig. 6476
Tool Countersink Plug Drill Drill Bits Overall Screw Stop Collar Stop Collar
Number Each Diameter No./Size (in.) Each Length Size No./Size (in.) Each
C2 $13.70 1/4" 5/64 $8.45 2" 2 1/4 $4.70
C4 13.70 5/16" 7/64 8.70 2-5/8" 4 — —
— — — 9/64 8.95 2-7/8" 4, 5 — —
C5 12.45 3/8" 1/8 8.45 2-3/4" 5 3/8 5.10 COUNTERSINKS
C6 12.45 3/8" 9/64 8.95 2-7/8" 6 3/8 5.10
C7 12.45 3/8" 5/32 8.95 3-1/8" 7 3/8 5.10
C8 12.45 3/8" 11/64 9.41 3-1/4" 8 3/8 5.10
C9 12.45 3/8" 3/16 9.80 3-1/2" 9 3/8 5.10
C913 12.45 3/8" 13/64 10.30 3-5/8" 10 3/8 5.10
C1014 13.70 7/16" 7/32 10.95 3-3/4" 12 3/8 5.10
— — — 9/64 8.95 2-7/8" 6 — —
— — — 11/64 9.41 3-1/4" 8 — —
— — — 3/16 9.80 3-1/2" 9 — —
C102 13.70 1/2" 13/64 10.30 3-5/8" 10 — —
C12 13.70 1/2" 7/32 10.95 3-3/4" 12 — —
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
Screw Driver Bits Plug Cutters

27367, 27368

27486
FIG 6478

FIG 9966 CUT YOUR OWN WOOD PLUGS
The tool cuts fast and makes a smooth CHAMFERED plug for
Phillips power bits are cold forged for optimum toughness and easy starting in the counterbored hole. Blades can be opened
resistance to wear. For driving heat-treated or case hardened for larger or closed for slightly smaller diameter plugs.
screws such as sheet metal, self-tapping and self-drilling. Plug Shank
PHILLIPS Diameter Each Length Diameter
No. Each Shank Length Point Size 1/4 $18.20 3/8" 1/4"
27367 $2.35 1/4" 3-1/2" 2 5/16 21.10 3/8" 1/4"
27368 2.95 1/4" 3-1/2" 3 3/8 23.50 1/2" 1/4"
SLOTTED 7/16 25.25 1/2" 1/4"
No. Each Shank Length Blade Size 1/2 30.00 1/2" 1/4"
27486 $6.40 1/4" 3-1/2" .050 (No. 12) For Teak Wood Deck Plugs — See Fig. 3618
