Float Switch and Strainers 337

Sure Bail Automatic Float Switch Bilge Pump Automatic Control Kit
®
For Bilge Pumps and High Water Alarm

24 E2

FIG 9415b

These float switches are spark free. The case gives complete
protection to the float and prevents switch failure due to for-
eign material lodging on or under the float. It also dampens the
wave action of bilge water while under way, preventing pump
cycling. The wires are always above the bilge water when
installed properly. 24 has a closed-tube mercury switch which
is sealed in a polyurethane foam float. Foam also cushions
high-speed G-forces of performance boats; protects mercury
switch from damage. The closed-cell foam can't waterlog and
the float can't come apart or stick — no close clearances. The
E2 electronic float switch starts pumps reliably and features a
dependable electronic, solid-state relay switch sealed in a FIG 3805
polyurethane foam float. Both have self-piloting screws for
easy installation. Operation can be checked manually by rotat- No float to stick or not float. Has a molded neoprene air bell
ing the external shaft. Rated: 15 Amps @ 6-32 Volts DC; 5 Amps with 3' flexible excelon air tube which makes installation easi-
@ 110 Volts AC. Size: 5-1/2" L x 2-1/2" W x 2-7/8" H. er. Is compatible with any model or voltage bilge pump. When
No. Each Volts Operating Water Levels GPH properly installed the switch is controlled by air pressure in the
E2 $88.95 All On @ 1-3/4", Off @ 7/8" All tube created by the rising bilge level. Switch cuts pump on at
24 41.85 All On @ 1-3/4", Off @ 7/8" All about 2-3/4" of bilge and off at about 1" of bilge. If possible,
mount air bell 6-12" from pump so switch is not affected by
Vacuum Switch suction of pump. Make electrical connections with wire of the
same size as used for pump power connections. Tube 3/16" ID.
Rated 115/230V AC at 15 Amps, 12V DC at 10 Amps, and 24 or
32V DC at 5 Amps.
No. Each Volts
AS100 $92.45 All
Bilge Strainers
FIG 4669
PIPE SIZE
When the bilge is dry or the vacuum on the suction line drops MOUNT SCREWS
to certain level, the pump is automatically shut off. Vacuum
switch prevents dry operation, thus saving impeller and parts A FLOAT SWITCH AND STRAINERS
life. May be fitted to suction side of any electric pump. Must be
manually started.
No. Each Ports Type
7046 $215.05 1/4" I.P.S. Electric B

Perko Bronze Bilge Pump Strainers
C

FIG 9928
FIG 709 FIG 722
Cast bronze with threaded IPS connection. Uses No. 10 fasten-
ers NOT included.
Fig. Each I.P.S. For Hose Size Std. Pkg. Dimensions
709 $68.40 — 5/8" 1-3/4" x 4" 5 No./Size Each A x B x C
722 140.30 1-1/4" — 2-3/4" x 4-3/4" 1 1-1/2 $94.75 3-3/8" x 3-5/8" x 2"
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov 2 248.95 5-1/4" x 3-5/8" x 2"
For Additional Strainers — See Fig. 7963
