454 Hose Adapters

Pipe-to-Hose Adapters Pipe-to-Hose Adapters

Full FIG 76
Flow
Made of cast bronze. The threaded por-
tion should be installed with pipe dope
or pipe tape. Use two stainless steel
FIG 9345 hose clamps on the barbed end.
No. Each IPS Male Hose ID Length
Full-flow adapters provide unrestricted full-pipe size flow, 1/2 $8.80 1/2" 1/2"-5/8" 2-3/16"
which is essential for maximum efficiency in engine cooling 3/4 12.05 3/4" 3/4" 2-3/16"
and other pumping applications. Fittings are cast bronze with a 1 18.95 1" 1" 2-1/2"
large hex for secure tightening. 1-1/4 26.20 1-1/4" 1-1/4" 2-3/4"
Note that the hose ID is larger than the pipe size. 1-1/2 37.75 1-1/2" 1-1/2" 3"
No. Each IPS Male Hose ID 2 57.10 2" 2" 3"
1/2 $9.50 1/2" 3/4" 2-1/2 87.80 2-1/2" 2-1/2" 4"
3/4 11.85 3/4" 1" 3 106.80 3" 3" 4"
1 14.80 1" 1-1/4" 4 156.25 4" 4" 4-1/4"
1-1/8 14.80 1" 1-1/8"
1-1/4 25.55 1-1/4" 1-1/2" 90° Pipe-to-Hose Adapters
1-1/2 30.00 1-1/2" 1-3/4"
2 58.15 2" 2-1/4"
2-1/2 78.95 2-1/2" 2-7/8"
3 127.50 3" 3-1/2" FIG 63
90° Pipe-to-Hose Adapters All cast bronze curved 90˚.
IPS Hose IPS Hose
No. Each Male ID No. Each Male ID
1/2 $21.20 1/2" 1/2" or 5/8" 1-1/2 $59.25 1-1/2" 1-1/2"
Full
3/4 19.35 3/4" 3/4" 2 104.75 2" 2"
Flow
1 30.55 1" 1" 2-1/2 127.80 2-1/2" 2-1/2"
1-1/4 49.95 1-1/4" 1-1/4" 3 165.65 3" 3"
FIG 9344
Pipe-to-Hose Adapters
Fittings are cast bronze with a large hex for secure tightening.
Full-flow adapters provide unrestricted full-pipe size flow, FIG 7943
which is essential for maximum efficiency in engine cooling
and other pumping applications. Made of yellow glass-reinforced
Note that the hose ID is larger than the pipe size. nylon which is exceptionally
No. Each IPS Male Hose ID strong and durable. Resistant to solvents, chemicals and mild
1/2 $14.95 1/2" 3/4" acids. The RPN Series hose nipples convert from male IPS
3/4 21.10 3/4" 1" threads to hose barbs. They have a temperature range of -30˚F.
1 30.20 1" 1-1/4" to +200˚F. under normal conditions.
1-1/8 29.80 1" 1-1/8" IPS Hose IPS Hose
1-1/4 131.05 1-1/4" 1-1/2" No. $3.20 Male 1/2" No. $4.95 1-1/4" 1-1/4"
48.05
Male
Each
ID
Each
ID
HOSE ADAPTERS 2-1/2 45° Pipe-to-Hose Adapters 2-7/8" 1 NOTE: Recommended for use with Tigerflex, reinforced clear
1-3/4"
1-1/2
1-1/2"
62.80
1/2"
1/2
1-1/4
2
2"
2-1/4"
3.40
1-1/2"
3/4"
1-1/2
1-1/2"
3/4
6.15
3/4"
2-1/2"
234.60
8.10
2
1"
4.10
2"
1"
2"
polybraid and any other hose with low stretch characteristics.
Standard Flow
Pipe-to-Hose Adapters
Straight and 100°
FIG 9343 FIG 9489 FIG 9490
All cast bronze curved 45°. Straight 100°
No. Each IPS Male Hose ID Made of ST801 nylon. Smooth wall allows faster flow.
3/4 $13.75 3/4" 3/4" Fig. 9489 Each Fig. 9490 Each IPS Male Hose ID
1 20.05 1" 1" 8001 $2.30 8021 $3.90 1/2" 5/8"
1-1/4 26.85 1-1/4" 1-1/4" 8002 2.40 8022 3.90 3/4" 3/4"
1-1/2 39.30 1-1/2" 1-1/2" 8003 4.00 8032† 5.60 1" 1"
2 55.95 2" 2" 8004 4.50 — — 1-1/4" 1-1/4"
2-1/2 91.75 2-1/2" 2-1/2" 8005 4.75 8057† 9.65 1-1/2" 1-1/2"
3 119.90 3" 3" †Short thread 8059 9.65 1-1/2" Hose ID 1-1/2"
For Stainless Steel Pipe-to-Hose Fittings — See Fig. 4076
