450 Ball Valves

Stainless Steel In-Line Bronze In-Line Full-Flow Ball Valves
Full-Flow Ball Valves IBV Series
IBVS Series FIG 4323

FIG 4325 The field reversible handle allows you to select the closed
position orientation (clockwise or counterclockwise) that best
suits the installation. It has a square hole to accept standard
The handle has a square hole to accept standard ratchet, to help reach valves in hard-to-reach loca-
ratchet (helps you to reach hard-to-reach valves tions and ease actuation of difficult to operate
and eases actuation of hard to operate valves). It valves. It's 400 WOG rated, has a stainless steel
has thumb-release locking mechanism to ensure handle and hardware, chrome-plated brass ball,
that the valve remains in the open or closed posi- PTFE seats and seals, and a bonding attachment.
tion you have selected until you wish to change Can be used for fuel or water.
it. It's 1000 WOG rated, has a #304 SS handle and No. Each Description
trim, #316 SS body and a bonding attachment 1/4 $22.70 1/4" IPS Full-Flow Valve
and TFE seats. Can be used for fuel or water. 3/8 22.70 3/8" IPS Full-Flow Valve
No. Each Description 1/2 31.50 1/2" IPS Full-Flow Valve
1/4 $51.55 1/4" IPS Full-Flow Valve 3/4 39.45 3/4" IPS Full-Flow Valve
3/8 55.10 3/8" IPS Full-Flow Valve 1 70.40 1" IPS Full-Flow Valve
1/2 66.60 1/2" IPS Full-Flow Valve 1-1/4 93.55 1-1/4" IPS Full-Flow Valve
3/4 71.25 3/4" IPS Full-Flow Valve 1-1/2 132.25 1-1/2" IPS Full-Flow Valve
1 74.75 1" IPS Full-Flow Valve 2 212.45 2" IPS Full-Flow Valve
1-1/4 118.70 1-1/4" IPS Full-Flow Valve 2-1/2 387.00 2-1/2" IPS Full-Flow Valve
1-1/2 153.50 1-1/2" IPS Full-Flow Valve Patented 3 633.35 3" IPS Full-Flow Valve
2 196.05 2" IPS Full-Flow Valve 4" Available on Special Order

Apollo Bronze Valves Gate Valves
Full-Flow
FIG 3595b
Made in
USA
Cast bronze valves are recommended for
FIG 6628 water, salt water, chemicals (slurry), oils and air lines. NOT rec-
ommended for gasoline or propane.
VALVE COMPLETE
Full-flow port valves have a chromium-plat- No./IPS Each No./IPS Each
ed ball; extremely hard wear surface 3/4" $38.90 1-1/2" $108.60
reduces friction, seat wear and erosive 1" 56.95 2" 149.65
effects. High-performance reinforced teflon
seats and stuffing box ring are standard. 600 psi, 1-1/4" 79.10 3" 389.30
WOG: for water, oil, gas or diesel fuel.
IPS/ Std. Bronze Thru-Hull Ball Valve Adapter
No. Each Port Diam.* Std. Pkg. IBVF Series
3/4 $102.90 3/4" 10
1 143.40 1" 5 FIG 4321
1-1/4 197.80 1-1/4" 5
1-1/2 244.15 1-1/2" 2
2 *Port diameter refers to the smallest opening in the valve 1 valves on top of a thru-hull fitting. Bottom thread is IPS to
424.70
No more DANGEROUS installations of in-line
2"
BALL VALVES WHILE Double Union Design valves. Permanently install IBVF adapter and screw on the ball
accept thru-hull fitting, top thread is IPS to accept standard ball
For Spare Handle and Nut — See Fig. 6625
valve later. Future valve replacement is simple.
PVC Ball Valves
Description
Each
No.
3/4
$51.50
3/4" All Bronze Adapter
58.90
1
1" All Bronze Adapter
SUPPLIES
1-1/2
1-1/2" All Bronze Adapter
80.70
LAST
2" All Bronze Adapter
96.75
2
2-1/2" and 3" Available on Special Order
NOT for Use with PVC Ball Valves
Potable Water
Compact Design
FIG 5702
FIG 5705
Has a PVC one piece body, ball, and stem
These full port valves are all PVC with Teflon seats and an with an ABS handle. Has santoprene seats
ABS handle. They INCLUDE: removable ends either female and seals. Fits schedule 40 or 80 pipe.
threaded or socket end. The ends are attached to the valve Maximum pressure: 150 PSI @ 100°F.
with an O-Ring and a threaded collar. They fit schedule 40 or No./IPS Each Description
80 pipe. Maximum pressure: 125 PSI at 72°F. 1/2 $3.25 Threaded End Ball Valve
No./IPS Each Description 3/4 3.95 Threaded End Ball Valve
1/2 $6.80 Socket or Threaded End Ball Valve 1 6.00 Threaded End Ball Valve
1 15.50 Socket or Threaded End Ball Valve 1-1/4 8.75 Threaded End Ball Valve
1-1/4 21.25 Socket or Threaded End Ball Valve 1-1/2 14.25 Threaded End Ball Valve
