Conbraco Apollo Straight WOG MEANS Conbraco Apollo Stainless
WATER, OIL, GAS OR
Bronze Ball Valves DIESEL FUEL WILL NOT Steel Straight Ball Valves
Made DAMAGE THESE VALVES.
in USA
Flow Diameter Refers
to Smallest Opening
Spare Handle in the Valve.

FIG 6625b Spare Nut

Can be used for inline installation in fuel line, water pressure Made
system, etc. Chrome-plated ball, extremely hard-wear surfaces in USA
reduce friction seat wear and erosive effects of steam and other
media. High-performance reinforced teflon seats and stuffing
box are standard. Stainless steel lever and nut. 600 PSI-WOG.
BALL VALVES
No. Each IPS Handle Flow Dia. Ctn.
1/4 $47.40 1/4" 1H 3/8" 10 FIG 6627
3/8 47.40 3/8" 1H 3/8" 10
1/2 47.40 1/2" 1H 1/2" 10 Has reinforced TFE seats and stuffing box rings. Has a 2,000
3/4 77.90 3/4" 2H 11/16" 10 PSI-WOG rating. 316 stainless steel.
1 95.65 1" 2H 7/8" 10 No. Each IPS Handle Flow Dia. Std. Ctn.
1-1/4 157.25 1-1/4" 3H 1" 5 3/8 $154.15 3/8" 1H 3/8" 10
1-1/2 197.55 1-1/2" 4H 1-1/4" 5 1/2 154.15 1/2" 1H 1/2" 10
2 240.90 2" 4H 1-1/2" 2 For Spare Handle & Nut — See Fig. 6625
2-1/2 1035.10 2-1/2" 4H 2-1/2" 1
3 1191.75 3" 4H 2-1/2" 1
SPARE HANDLES Conbraco Apollo 5-Port Ball Valves
1H 11.45 4-1/2" Long, uses 3/8"-24 Jam Nut 5
2H 17.85 5-3/8" Long, uses 7/16"-20 Jam Nut 5
3H 19.55 6-1/4" Long, uses 7/16"-20 Jam Nut 5
4H 23.15 8-3/4" Long, uses 7/16"-20 Jam Nut 5
6H 105.45 11-1/2" Long, uses 1/2"-20 Jam Nut 5 Made
SPARE JAM NUTS in USA
3/8-24* 0.70 3/8"-24 Stainless Steel 100
7/16-20* 1.35 7/16"-20 Stainless Steel 50
1/2-20* 1.80 1/2"-20 Stainless Steel 50
* WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
Conbraco Apollo Straight Bronze Valves
With Mounting Ears FIG 6626
Made
in USA FIG 5570 Both sizes have a ball valve. All brass with stainless steel trim.
Four 1/4"-20 top-mounting tappings for easy installation.
Factory tested to 30 PSI air. WOG.
For inline installations in fuel lines, water pres-
sure systems, etc. 400 PSI–WOG. Flow
Handle Flow No. Each Diameter Female Ports
No. Each IPS No. Diameter Std. Ctn. 3/4 $531.70 3/4" 5-3/4" IPS Female
1/4 $66.10 1/4" 1H 3/8" 10 1/2 205.80 7/16" 5-1/2" IPS Female
3/8 66.10 3/8" 1H 3/8" 10 For Spare 7/16"–20 Nut — See Fig. 6625 VALVES
1/2 66.10 1/2" 1H 1/2" 10
3/4 91.45 3/4" 2H 11/16" 10 Bronze 3-Way Valve TWV Series
For Spare Handle & Nut — See Fig. 6625
Brass 6-Port Fuel Valve
OPENINGS: With Handle Over 2:
Open: 2-3-4-6, Closed 1-5
With Handle Over 3:
3
Open: 1-3-4-5, Closed: 2 & 6
With Handle Over 1:
Open: 1-5, Closed: 2-3-4-6
1
2 FIG 9836
5
6
This cast brass valve is used where FIG 4324
two tanks supply a single engine and
4 a return to each supply tank is
required. Has a closed bottom with O-ring sealed cap and This full-flow three-way valve has a stainless steel stem, han-
stem which eliminates external leakage. Recommended for dle, and hardware. The handle points in the direction of flow. It
diesel fuel systems. Temperature Rating: -40° to + 180°F at 15 rotates 180° and the center position is off.
PSI. Has four 1/4" female mounting holes. No. Each Description
Supply IPS Return 1/2 $55.65 1/2" IPS Full-Flow Valve
No. Each 1-2-3 4-5-6 3/4 67.00 3/4" IPS Full-Flow Valve
FV65038 $239.95 1/2" 3/8" 1-1/2 270.70 1-1/2" IPS Full-Flow Valve
