452 Valves

Four-Way Valve Conbraco Apollo
Bronze 3-Way Valve
OPENINGS: With Handle Over 2*:
Open: 1-4, Closed: 2-3
With Handle Over 3:
1-3/8" All Closed Made
With Handle Over 1: in USA
Open: 2-4, Closed: 1-3
1 With Handle Over Back:
2
Open: 3-4, Closed: 1-2
*As shown in picture
3 4
FIG 6855
FIG 3545
Reinforced TFE seats and seals. The chrome-plated balls hard
1/4" four-way long stem brass valve. For mounting below deck surface resists scoring. Large ports for less pressure drop. Open
or behind bulkhead. INCLUDES mounting flange. port pressure must exceed closed port pressure. 400 PSI–WOG.
No. Each Description No. Each IPS Handle Flow Dia. Std. Ctn.
255 $54.00 1/4" Female IPS 1/2 $75.20 1/2" 1H 1/2" 6
3/4 101.65 3/4" 2H 11/16" 6
Four-Way Tank Selector Valve 1 132.10 1" 2H 13/16" 6
1-1/4 212.20 1-1/4" 3H 1" 5
Full Port 1/2" Flow 1-1/2 246.00 1-1/2" 3H 1-1/4" 5
2 349.30 2" 3H 1-1/2" 2
For Spare Handle & Nut — See Fig. 6625
FIG 8974
Shut-Off Valves
For fuel or water. Four positions: Tank-1, Tank-2,
Tanks 1 & 2, Off. Full 1/2" flow. Audible 'click' at
each handle position. For thru-panel mounting.
Use (4) No. 10-24 screws NOT included.
No. Each Description
FV450X $119.90 1/2" IPS 4-way Tank Selector Valve
FV Series Fuel Valves 401M 429M

FIG 3456

B.I.A. recommends a shut-off valve in fuel line for anti-syphon
protection. Shut-off valves are cast brass with 1/4" IPS male
and female ports. Flare Fittings are S.A.E. 45°.
No. Each Description
FIG 8975 401M $46.10 1/4" Male to 1/4" Female Port
429M 52.00 1/4" Male to 3/8" Male Flare
Standard Package – 5
VALVES pendent means of support. That's why regular in-line valves are Three-Way Valves
ABYC H33.9.2 states that fuel system valves must have an inde-
not appropriate for fuel systems applications. These have a
patented field selectable handle rotation and are full flow. They
include a mount foot. Stainless steel handle and hardware, 400
WOG, and PTFE seats and seals. They are also UL listed for fuel.
No. Each IPS
1/4 $20.75 1/4"
3/8 20.75 3/8"
1/2 30.75 1/2"
3/4 38.05 3/4"

One-Piece Shut-Off Valves

244 252

FIG 3457

Three-way valve is cast brass, with three 1/4" or 3/8" IPS
FIG 1923 female ports. Use to connect two permanent tanks to a single
motor. Withdrawal from one tank at one time only.
No. Each Ports Description
These ultra-flow ball valves offer maximum fuel flow. 244 $49.40 1/4" One Port Down
No. Each Description 252 54.10 3/8" Side Hook-Up
46-443 $36.05 Brass 1/4" Male IPS x 1/4" Female IPS Standard Package – 5
