Page 497 - Lewis

496 Hynautic Steering Accessories

Oil Reservoirs FIG 1HYN Reservoirs
Unless Noted
C

Old Hynautic
RV55 picture
A shown for
dimensional
B
purpose only
160103
DIMENSIONS HP6122
A B C
HP5860HY 9" 11" 5-1/2" HP6040
HP5855HY 9" 11" 5-1/2"
These oil reservoirs are a 2 component item which consists of
a reservoir and the appropriate relief valve. Also includes a C
pressure gauge and fittings. Has a one quart capacity. These
replace the discontinued one part reservalves used on old H50
helm systems. R13 HP5810HY
No. Each P.S.I. Tubing A B
Fig. 6564 HP5855 HY $1002.65 500 3/8" – Nylon-MST2 DIMENSIONS
Fig. 6564 HP5860HY 1069.55 950 3/8" – Copper A B C
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov HP5810HY 9-1/2" 13-5/8" 4-7/8"
R13 12-1/4" 16-3/4" 6"
Relief Valves
No. Each Description
C DIMENSIONS R04 $725.15 Reservoir with 0-100 PSI Gauge Controls
A A B C R13 1093.75 Complete– INCLUDES R04 & MCV04 in
MSV19 3-7/8" 2-1/2" 1"
MSV21 3-7/8" 2-1/2" 1" one Unit
RS01 52.50 Reservoir Seal Kit
B MSRF01 105.60 Fittings for 3/8" Lines – Copper
MCRF04 49.85 Fitting Package for R04
3-PORTED — FOR USE WITH ALL CURRENT SYSTEMS
No. Each Description Fig. 6564 HP5810HY 762.20 Oil Reservoir for MS Steering
91.60 Air Filler Plug
Fig. 6564 HP6040
MSV19 $247.45 500 PSI, Use with Nylon Tubing
MSV21 273.80 950 PSI, Use with Copper Tubing Fig. 6564 HP6122 30.85 Air Fill Valve Only for Reservoir
Fig. 6564 HS5199
20.05 Seal Kit for HP5810HY Oil Reservoir
RELIEF VALVE FITTING PACKAGES
No. Each Use With 160012 14.75 0-60 PSI Pressure Gauge for Reservoir
MSVF13 $66.35 MSV21 – 1/2" Copper Only for HYD. Steering 1/8 IPS
160042 22.25 0-60 PSI Pressure Gauge, Back Mount
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
for HYD. Steering 1/8 IPS
160052 50.80 0-150 PSI Pressure Gauge for Reservoir
Ball Joints for Cylinder and Tie Bars for HYD. Controls 1/4 IPS
160103 19.40 Gold Filter Element for 380060
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
HP6003
FIG 6564 Bulkhead Fitting
Female Thread Fits Fits
HYNAUTIC STEERING ACCESS.
No. Each x Bolt Hole ID Cylinder Tie Bar
HP6003 $104.60 1/2" x 3/8" HC5392 HO5001
HO5004 HO5003
HP6013 147.60 5/8" x 5/8" HC5318, HC5319 —
HC5349, HC5350
HC5351, HC5353
HC5354 3/8 x 3/8
HP6019 303.55 3/4" x 3/4" Older P/S — No. Each Description
Cylinder 3/8x3/8 $11.50 3/8" Male Flare x 3/8" Female Flare Elbow
HP6077 104.60 1/2" x 1/2" HC5312, HC5313 — WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
HC5314, HC5315
HC5316, HC5317
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov Ball Joints and Miscellaneous Parts
Cylinder/Tie Bar Ball Joints
Stainless Steel

FIG 6565 CL50 HP6039
Female Thread No. Each Description
No. Each x Bolt Hole ID Fig. 865 CL50 $43.20 Clevis 1/2" IPS, Bronze, 3-1/2" Long, 1/2" Pin,
SSPF6001 $48.85 1/2" x 3/8" 3/4" Jaw Opening (pictured in Fig. 865)
SSPF8001 69.65 1/2" x 1/2" Fig. 6564 HP6039 289.95 Straight Brass Ball Joint for Rigid Mount K22 –
SSPF10001 83.35 5/8" x 5/8" K29, 1/2" IPS Female x 1/2"-20 Male Thread
SSPF12001 121.20 3/4" x 3/4" For Additional Clevises — See Fig. 865
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
