Hynautic Marine Hydraulic Throttle and Clutch Controls
Hynautic hydraulic controls at each station operate in synchronization. Operating the levers through a complete stroke at any station synchro-
nizes all stations. A special pilot check valve hydraulically locks the throttle position without adding friction to the system. All components are
connected with 5/16" nylon tubing, easy to string and run. All connections are made with leak-proof tube fittings. Throttle and clutch control sys-
tem's component parts are marine aluminum alloy, stainless steel or brass. The control heads are made of marine aluminum alloy No. 6061 and
are brush finished and anodized. See the following page for the system that fits your application.
CAUTION!
This System does NOT use Oil. Use 50/50 (By Volume) Ethylene – Glycol Distilled Water. Do Not Use Stop-Leak type Anti-Freeze
Single Head Sender Dual Head Sender

Hynautic systems are designed to
FIG 1HYN deliver up to 120 inch pounds of
torque at the slave thru 80° of travel.
Controls one function only.
No. Each Description FIG 1HYN
CL04 $801.45 Single Left Head Sender
CR04 801.45 Single Right Head Sender CD04 controls two functions, two throttles, two transmissions, or
610048 19.90 Spare 2" Black Plastic Knob one throttle and one transmission. Mounting plate INCLUDED.
610058 19.90 Spare 2" Red Plastic Knob No. Each Description
ECS05 52.25 Seal Kit For CL04 & CR04 CD04 $1570.30 Dual Head Sender
For Spare 2" Aluminum Round Knobs — See Fig. 3937 CDF04 58.10 Spare Dual-Head Mtg. Plate
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
Charging Valve R04 Reservoirs
Reservoir R13
without Reservoir with
Charging Charging Valve
For old style Valve
systems when
MCV04
separate from
reservoir 900430
Charging Valve Only FIG 1HYN
The reservoir maintains positive fluid pressure to the charging
FIG 1HYN valve at all times. R13 incorporates the R04 reservoir and
900430 charging valve into a single unit. Mounts the same as
the R04.
This valve keeps all systems under positive fluid pressure at all No. Each Description
times. MCVF08 is used on single charging valve applications. R04 $725.15 Reservoir Only
No. Each Description R13 1093.75 Reservoir w/ 900430 Charging Valve
MCV04 $315.30 Charging Valve 900430 274.00 Spare Charging Valve for R13
MCVF08 190.50 Upgrade Kit – Single MCRF04 49.85 Reservoir Fitting Package R04
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
Shift and Throttle Fluid

For control systems Only
FIG 6564 50/50 water/pure Ethylene Glycol HYNAUTIC CONTROLS
No. Each Size Description
HA5455 $74.65 Gallon Shift and Throttle Fluid
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
Transmission and Throttle Slave
SS04

ST06 670010
FIG 1HYN

SS04 Transmission Slave INCLUDES neutral detents. STO6 Throttle Slave incorporates the ST04 Throttle Slave and the STV10 Pilot
Check Valve into one unit. 670010 Ball Joint is for use with these slaves.
No. Each Description No. Each Description
SS04 $704.25 Transmission Slave STF12 $162.90 Fittings for ST06 (Nylon Tubing)
ST04 635.50 Throttle Slave Only STV10 168.15 Pilot Check Valve
ST06 759.05 Throttle Slave/Pilot Check Valve Unit 670010 45.05 Ball Joint 1/4"-20 Fem. x 1/4"-28 Male for ST04 & ST06
ECS06 52.25 Seal Kit for ST04, ST06, SS04 & SS06 690010 13.40 Spare Bleeder Valves for ST04 & ST06
STF10 226.80 Fittings for ST04 (Nylon Tubing) 850081 121.00 Bungee Assembly for ST04 & ST06
